Cảm biến vùng Panasonic SF4D-A24-01

Name: Cảm biến vùng Panasonic SF4D-A24-01
Brand: Panasonic
SKU: SF4D-A24-01
Availability: InStock

SF4D Robust Safety Light Curtain Series

Slim and robust construction resists twisting, warping and impact
Dead zoneless design enables easy calculation of safe distance.
Enviromental: IP67/IP65 (IEC) & NEMA Type 13 (NEMA 250)
Type 4 – 40mm beam spacing for Arm/Foot Protection Type
12 beam channels provide 230mm protection height
15 meter sensing distance when set in Long Mode
Not compatible with SF4D-TM1 Communication Module or Configurator Software
Not compatible with options that include blanking & muting
Mounting brkts and cables must be ordered separately

47.837.000 ₫

SKU: SF4D-A24-01 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
SF4D
Light Curtain Type & Style
Type 4-Compact & Robust
Protection Type
Arm/Foot
Number of Beams
24 beam channels
Beam Pitch
40mm
Minimum Detectable Object
Ø 45mm
Protection Height
950mm
Features
Slim and robust construction resists twisting, warping and impact. Series connection of up to 5 units
Light Source
Infrared LED
Effective Aperture
±2.5° or less
Safety Rated Control Outputs
NPN/PNP x 2
Safety Control Output Response Time
OFF response: <10 ms (Not connected in series/parallel), <18 ms (Connected in series / parallel). ON response: <50 ms
Voltage Details
24VDC, +20% / -30% Ripple P-P 10 % or less
Temperature
–10 to +55 °C
Protection
IP67, (IP65 IEC), NEMA Type 13
Construction
Enclosure: Aluminum, Detection surface: Polycarbonate resin and stainless steel, Upper/lower cap: nylon
Connection Type
QD or Cabled
Connection Type Detail
Select SF4D Bottom Cap Style
Item Weight
5.22 lbs per EA
