Cảm biến quang Panasonic EX-13B-R

Incredibly Small Photoelectric Sensor with Built-In Amplifier
Smallest Body – Just 3.5 mm (.138”) Thick With incredibly small dimensions, the EX-10 series can be mounted in very small spaces. 10mm W x 14.5mm H x 3.5mm D.394” W x .571” H x .138” D (thru-beam, front sensing type)
Key Features:

Panasonic (formerly Sunx) Ultra Slim Miniature Photoelectric Sensor
12 to 24 VDC
Front Sensing Type. Only 3.5mm thick
Thrubeam sensing with Red LED light source
Sensing range 500 mm
NPN output Dark-On mode
2 meter robotic connection cable
EX-13B-R includes the following 2 part numbers: EX-13P-R (Projector Portion) and EX-13BD-R (Detector Portion)

2.482.000 ₫

Báo giá
SKU: EX-13B-R Danh mục: Thương hiệu:
Dòng sản phẩmEX-10
Kiểu thân cảm biếnMiniature Ultra-thin
Đặc điểm thân cảm biếnFront sense 3.5mm thick, H19 x W10
Chế độ phát hiệnThrubeam
Chi tiết chế độ phát hiệnø2.0mm Min Detectable Object
Đặc điểm cảm biếnRepeat accuracy of 0.05mm, high speed response of 0.5ms
Nguồn sángLED đỏ
Thông số nguồn cấp12 to 24VDC
Phạm vi phát hiện500mm
Ngõ raNPN
Chi tiết ngõ ra1 each NPN
Chức năng TimerKhông
Chế độ ngõ raDark-On
Cấu tạoPolyethylene terephthalate enclosure, Polyalylate lens
Nhiệt độ-20º to +55º C
Cấp bảo vệ IEC/NEMAIP67
Chi tiết kết nốiCable 2m Robotic
Khối lượng1.00 lbs per EA

Thông tin bổ sung

Thương hiệu

Panasonic
