Cảm biến vùng Panasonic SF4C-H24-J05

Name: Cảm biến vùng Panasonic SF4C-H24-J05
Brand: Panasonic
SKU: SF4C-H24-J05
Availability: InStock

Panasonic (formerly Sunx) SF4C Series Ultra-slim Light Curtain
Category 4 protection 20mm beam spacing
Switch selectable NPN/PNP output
24 beam channels provide 480mm protection height
0.1 to 3m sensing distance
500mm long molded pigtail connection

29.906.000 ₫

Mã sản phẩm: SF4C-H24-J05 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
SF4C
Light Curtain Type & Style
Type 4-Ultra-Slim
Protection Type
Hand
Number of Beams
24 beam channels
Beam Pitch
20mm
Minimum Detectable Object
Ø 25mm
Protection Height
480mm
Operation Range
0.1 to 3 meters
Features
Solid choice for light-duty assembly machines. Only 13.2mm Thick! Large bright multi-purpose LED indicators
Light Source
Infrared LED
Effective Aperture
±2.5° or less
Safety Rated Control Outputs
NPN/PNP x 2
Safety Control Output Response Time
OFF response 7 ms or less, ON response 90 ms or less
Voltage Details
24VDC +10%/-15% Ripple P-P 10% or less
Temperature
–10 to +55 °C
Protection
IP67, IP65 (IEC)
Construction
Polycarbonate alloy enclosure and sensing surface
Connection Type
QD Pigtail
Connection Type Detail
Select SF4C Extension Cable
Item Weight
1.68 lbs per EA
