| Dòng sản phẩm | FX-551 |
| Tình trạng sản phẩm | Mẫu hiện hành |
| Kiểu cài đặt | PB Teaching |
| Chi tiết kiểu cài đặt | PB Teach with fine adjust |
| Kiểu hiển thị | Màn hình LED kỹ thuật số |
| Chi tiết hiển thị | Dual 4-digit Red/Grn display,LED Status Indicators |
| Đặc điểm nổi bật | IO-LINK compatible fiber amp provides bi-directional communication between the sensor data and IO-LINK Master. IODD files available for process data, Parameter Data, and self diagnostic monitoring. |
| Nguồn sáng | LED đỏ |
| Loại bộ khuếch đại | Loại độc lập |
| Loại ngõ ra | IO-LINK, PNP |
| Chi tiết ngõ ra | IO-LINK, PNP |
| Kiểu kết nối | Cable |
| Chi tiết kết nối | 2 Meter Cable |
| Điện áp nguồn cấp | Một chiều (DC) |
| Thông số điện áp | 12 to 24VDC |
| Thời gian đáp ứng nhanh nhất | 250µs |
| Tùy chọn trễ thời gian | Multifunction |
| Tùy chọn bộ đếm | Không |
| Chức năng ngõ vào từ xa | Không |
| Chống nhiễu chéo | Up to 4 units |
| Cấp bảo vệ | IP40 |
| Khối lượng | 0.18 lbs per EA |
Bộ khuếch đại sợi quang Panasonic FX-551L3-P-C2
IO Link Compatible
This FX-551L IO link fiber amplifer is IO link compatible. Open communication technology with bi-directional communication between the sensor and the IO link Master. IODD files available for process data, Parameter Data, and self diagnostic monitoring data.
Increased Sensing Distance
The sensing range of the standard diffuse reflective type fiber is about 1.6 times longer than that of a conventional product. This adds extra flexibility to the sensor layout.
Simple Threshold Adjustment
The FX-551 Series can easily setup with just a few clicks of the teach button. Threshold can also be easily adjusted while in operation allowing for quick fine tuning of the sensor.
Ambient Light Compensation Function
If the sensor is around bright ambient light the compensation function can be set up to help avoid interference from stray lighting.
3.244.000 ₫
Thông tin bổ sung
| Thương hiệu | Panasonic |
|---|
