Bộ khuếch đại sợi quang Panasonic FX-412

Name: Bộ khuếch đại sợi quang Panasonic FX-412
Brand: Panasonic
SKU: FX-412
Availability: InStock

Panasonic (formerly Sunx) digital display amplifier with easy to use multi-turn sensitivity adjusterComes with adjustment knob that can be adjusted with fingers12 to 24 VDC inputNPN outputRed LED light sourceRequires Panasonic CN-73 hook-up cable which is sold separately. See recommended products below.

4.262.000 ₫

Mã sản phẩm: FX-412 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FX-410
Remove Discontinued
Currrent Model
Setting Type
Manual Adjustment
Setting Type Detail
Potentiometer Multi-turn
Display Type
Digital LED Display
Display Detail
Dual 4-digit Red/Grn display,LED Status Indicators
Features
Unique design with multi-turn pot and digital display of threshold and incident light level. Four levels of light emissionto eliminate saturation. Peak/Hold function.
Light Source
Red LED
Amplifier Type
Interconnect Type – Master/Slave
Output Type
NPN
Output Details
1 each NPN
Connection Type
Cable w/conn
Connection Details
Use CN-70 Series Connector/cable
Supply Voltage
DC
Voltage Details
12 to 24VDC
Fastest Respose Time
150µs
Time Delay Option
Multifunction
Counter Option
No
Remote Input Feature
No
Cross Talk Prevention
Up to 8 Units (Main/Sub)
Item Weight
0.40 lbs per EA
