| Dòng sản phẩm | FT/FD/FR |
| Đặc tính chính | Limited Distance |
| Chế độ phát hiện | Convergent |
| Đặc tính kỹ thuật | Front Sensing |
| Ống kính tương thích | Not Compatible With Add-On Lens |
| Kiểu thân lắp đặt | Square/Rectangular |
| Kích thước lắp đặt | 12mm x 19mm x 3mm |
| Đặc điểm cáp quang | Sensing Distance is limited to a specific range and is not easily affected by the background. Works Well for Glass Substrate Detection and Seating Confirmation |
| Bán kính uốn cáp quang | R4 High-flex |
| Có thể cắt/Không thể cắt | Cuttable |
| Chiều dài sợi quang | 2 meter |
| Lõi sợi quang | Ø 0.75 / Ø 0.5mm |
| Nhiệt độ định mức | -40 to +60° C |
| Phụ kiện đi kèm | FX-AT6 black/grey attachment w/tips for Ø2.2 / Ø1.0mm cuttable fibers, and fiber cutter |
Cảm biến sợi quang Panasonic FD-L10
Panasonic (formerly Sunx) Convergent Fiber Optic Cable for Glass Substrate DetectionUltra-slim design is only 3 mm thickFeatures convergent reflective design for detection of LCD glassSensing distance of 0 to 5.5 mm2 meter high-flex free cut fiber optic cable with 4 mm bending radius
FD-L10 Dimensional Drawing
4.032.000 ₫
Thông tin bổ sung
| Thương hiệu | Panasonic |
|---|
