Cảm biến quang Panasonic CX-443-Z

Name: Cảm biến quang Panasonic CX-443-Z
Brand: Panasonic
SKU: CX-443-Z
Availability: InStock

Panasonic (formerly Sunx) Photoelectric Sensor with Programmable Background and Foreground Suppression Sensing Modes Red LED source 12 to 24 VDC supply with NPN output selectable LO and DO mode Compact housing features 20 to 50mm distance and M8 4 Pin 5-turn adjustment potentiometer. 1ms response
This item will be discontinued on September 25th , 2020. Please stock up while supplies last

2.385.000 ₫

Mã sản phẩm: CX-443-Z Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
CX-400
Sensor Body Type
Compact Rectangular Plastic
Sensor Body Feature
H31 x W11 x D20, ethanol resistant
Sensing Mode
Background/Foreground Suppression
Sensing Mode Details
Hysteresis of 2%
Sensor Features
5-turn pot, Detects height difference of 0.4mm, perpendicular accuracy 0.2mm
Light Source
Red LED
Supply Voltage Details
12 to 24VDC
Sensing Range
2mm to 50mm
Output
NPN
Output Details
1 each NPN
Timer
No
Output Mode
Light-On/Dark-On selectable
Construction
PBT enclosure, Polycarbonate lens
Temperature
-25º to +55º C
IEC/Nema Rating Details
IP67
Connection Detail
M8 4P QD
Item Weight
1.00 lbs per EA
