Cảm biến quang Panasonic SH-82G

Cảm biến quang Panasonic SH-82G

Effective the end of September, 2021 this sensor will be discontinued. Contact Ramco for suggested replacement optionsPanasonic (formerly Sunx) SH Series Pinpoint Mark Sensing Photoelectric SensorRequires SU-7 style amplifier (order separately)10 to 14mm range with convergent point of 12mmGreen LED source with Spot diameter of 1.0mm

2.805.000 ₫

Mã sản phẩm: SH-82G Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
SU7/SH
Sensor Body Type
Ultra-Compact Plastic
Sensor Body Feature
Side sense 8mm thick, H25 x W15
Sensing Mode
Diffuse
Sensing Mode Details
Mark Sensing, detects 0.2mm black line on white
Sensor Features
Small Beam Spot for Mark Sensing, Requires SU-7 Style Amplifier
Light Source
Green LED
Supply Voltage Details
12 to 24VDC
Sensing Range
10mm to 14mm
Output
NPN or PNP
Output Details
1 each NPN or PNP
Timer
No
Output Mode
Light-On/Dark-On selectable
Construction
Polycarbonate enclosure, Acrylic lens
Temperature
-10º to +55º C
Connection Detail
Cable Shielded 2m
Item Weight
0.09 lbs per EA

Thông tin bổ sung

Thương hiệu	Panasonic
