Cảm biến vùng Panasonic SF4D-H8-01

Cảm biến vùng Panasonic SF4D-H8-01

SF4D Robust Safety Light Curtain Series

Slim and robust construction resists twisting, warping and impact
Dead zoneless design enables easy calculation of safe distance.
Enviromental: IP67/IP65 (IEC) & NEMA Type 13 (NEMA 250)
Type 4 – 20mm beam spacing for Hand Protection Type
48 beam channels provide 950mm protection height
12 meter sensing distance when set in Long Mode
Not compatible with SF4D-TM1 Communication Module or Configurator Software
Not compatible with options that include blanking & muting
Mounting brkts and cables must be ordered separately

18.102.000 ₫

Mã sản phẩm: SF4D-H8-01 Danh mục: Thương hiệu:

Item Specifications

  • SF4D
  • Type 4-Compact & Robust
  • Hand
  • 8 beam channels
  • 20mm
  • Ø 25mm
  • 150mm
  • Slim and robust construction resists twisting, warping and impact. Series connection of up to 5 units
  • Infrared LED
  • ±2.5° or less
  • NPN/PNP x 2
  • OFF response: <10 ms (Not connected in series/parallel), <18 ms (Connected in series / parallel). ON response: <50 ms
  • 24VDC, +20% / -30% Ripple P-P 10 % or less
  • –10 to +55 °C
  • IP67, (IP65 IEC), NEMA Type 13
  • Enclosure: Aluminum, Detection surface: Polycarbonate resin and stainless steel, Upper/lower cap: nylon
  • QD or Cabled
  • Select SF4D Bottom Cap Style
  • 0.61 lbs per EA
Thương hiệu

Panasonic
