| Dòng sản phẩm | PM25 |
| Chế độ phát hiện | Slot sensor – amplifier built-in |
| Khoảng cách phát hiện | 6mm |
| Nguồn sáng | Infrared LED non-modulated |
| Vật thể nhỏ nhất có thể phát hiện | 0.8 × 1.2mm opaque object |
| Độ trễ | < 0.05mm |
| Độ lặp lại | < 0.01mm |
| Điện áp nguồn cấp | 5 to 24VDC |
| Dòng điện tiêu thụ | < 15mA |
| Ngõ ra | NPN x 2 |
| Chế độ ngõ ra | LIght-On and Dark-On |
| Nhiệt độ hoạt động | –25 to +55 °C |
| Cấp bảo vệ IP | IP64 |
| Vỏ bảo vệ | PBT enclosure, polycarbonate display section |
| Chi tiết phương thức kết nối | Cable 1 meter |
| Khối lượng | 0.04 lbs per EA |
Cảm biến quang Panasonic PM-U25
Panasonic (formerly Sunx) PM-U25 Micro Slot sensor with 6mm slot. Featuring industry first IP64 rating. Three protection circuits are standard
1. Reverse supply polarity protection
2. Reverse output polarity protection circuit
3. Output short-circuit protection circuit
288.000 ₫
Thông tin bổ sung
| Thương hiệu | Panasonic |
|---|
