Name: PLC Keyence KV-NC32T (16 in/ 16 out transistor)
Brand: Keyence
SKU: KV-NC32T
Availability: InStock

Thông số	Giá trị
Model	KV-NC32T
Power voltage	24 VDC (+10%/-15%)
Operating ambient temperature	0 to 55°C (32 to 131°F) (no freezing)
Operating ambient humidity	5 to 95% RH (no condensation)
Operating environment	As little dust and corrosive gas as possible
Noise immunity	1500 V peak-to-peak or more, pulse duration 1 μs, 50 ns (based on noise simulator) Conforms to IEC standards (IEC61000-4-2/3/4/6)
Withstand voltage	1500 VAC for 1 minute, between power supply terminal and I/O terminals and between all external terminals and case (1000 VAC for 1 minute, between power supply terminal and output terminals for the transistor output type expansion I/O unit)
Insulation resistance	50 MΩ or more (500 VDC megger used to perform measurements between power supply terminal and input terminals, and between all external terminals and case)
Storage temperature	−25 to +75°C (−13 to +167°F)
Vibration resistance (Intermittent vibration)	Frequency: 5 to 9 Hz, Amplitude: 3.5 mm (0.14″)
Vibration resistance (Continuous vibration)	Frequency: 9 to 150 Hz, Acceleration: 9.8 m/s² (32.2’/s²)
Shock resistance	Acceleration: 150 m/s² (492.1’/s²), application time: 11 ms, three times in each of the X, Y, and Z directions
Operating altitude	2000 m (6561.7′)
Overvoltage category	I
Pollution degree	2
Calculation control method	Program storage method
I/O control method	Refresh method
Program language	Expanded ladder, KV Script, mnemonic
Number of instructions	Basic instruction: 81 types and 182 instructions, Application instruction: 39 types and 56 instructions, Calculation instruction: 123 types and 311 instructions, Expansion instruction: 92 types and 141 instructions, Total: 335 types and 690 instructions
Instruction execution speed	Basic instruction: 50 ns minimum, Application instruction: 170 ns minimum
Program capacity	32k steps
Maximum number of attachable I/O units	8
Maximum number of I/O points	256
Input relay/Output relay/Internal auxiliary relay	Total of 9600 points 1 bit (R000 to R59915)
Link relay	8192 points 1 bit (B0 to B1FFF)
Internal auxiliary relay	9600 points 1 bit (MR000 to MR59915)
Latch relay	3200 points 1 bit (LR000 to LR19915)
Control relay	1440 points 1 bit (CR000 to CR8915)
Timer	512 points 32 bits (T0 to T511)
Counter	256 points 32 bits (C0 to C255)
Data memory	32768 points 16 bit (DM0 to DM32767)
Link register	16384 points 16 bit (W0 to W3FFF)
Temporary memory	512 points 16 bit (TM0 to TM511)
High-speed counter	3 points (CTH0 to CTH2), 32-bit automatic reset counter (Input response: 100 kHz per single phase, 50 kHz per phase difference)
High-speed counter comparator	6 points (CTC0 to CTC5), 32 bits, two points per high-speed counter
Index register	12 points 32 bit (Z01 to Z12)
Control memory	9000 points 16 bit (CM0 to CM8999)
Positioning pulse output	3 axes, Maximum output frequency: 100 kHz
Base unit I/O	Input: 16 points, Output: 16 points, Input common: 1 point, Output common: 1 point
Number of comments and labels that can be stored in the main unit	Device comment: 20000, Label: 28000
Power off hold function	Program memory: Flash ROM can be rewritten 10000 times, Device: Nonvolatile RAM
Clock function	±60 seconds/month (at 25°C / 77°F)
Self-diagnosis function	CPU error, RAM error, and other problems
Input specifications	Relay number: General input: R000 to R009 (10 points), High-speed A-phase and B-phase input: R010 to R015 (6 points)
Input mode	24 VDC input (open collector)
Maximum input voltage	26.4 VDC
Rated input voltage	24 VDC (General input: 5.3 mA, High-speed A-phase and B-phase input: 6.5 mA)
Minimum ON voltage	19 VDC
Maximum OFF current	1.5 mA
Common method	All points/1 common (1 terminal)
Circuit delay time	General input: OFF to ON: Max. 30 μs (Typ. 3.5 μs), ON to OFF: Max. 50 μs (Typ. 15 μs)
Input time constant	Normal: 10 ms, When the HSP instruction is used: 10 μs
Response frequency	(High-speed A-phase and B-phase input) Single phase: 100 kHz, phase difference: 50 kHz, 24 V ±10%, Duty 50%
Output specifications	Relay number: General output: R506 to R515 (10 points), High-speed output: R500 to R505 (6 points)
Output mode	MOSFET (N-ch) output
Rated load	30 VDC, General output: 0.2 A (1.6 A/common), High-speed output: 0.3 A (1.6 A/common)
Maximum OFF voltage	30 VDC
Leakage current at OFF	100 μA or less
Residual voltage at ON	0.6 VDC or less
Common method	16 points/1 common
ON/OFF response time	General output: OFF to ON: 100 μs, ON to OFF: 200 μs, High-speed output: OFF to ON: 2 μs, ON to OFF: 5 μs
Overcurrent protection	Protection provided for each common
Output frequency	High-speed output: 100 kHz (7 to 100 mA load)
Built-in serial port	Interface: RS-232C, Connection: Modular connector
Transmission specifications RS-232C	Baud rate: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
Connector type	Modular connector (RJ-11 6P2C) (two lines)
Communication length	15 m (49.2′)
Protocol	ASCII, ADPN, K-servo, Host terminal monitoring
Proximity sensors	Distance: 6 to 24 VDC, Output: 2 points
