Name: PLC Keyence KV-N60AT (36 in/ 24 out transistor)
Brand: Keyence
SKU: KV-N60AT
Availability: InStock

Thông số	Giá trị
Model	KV-N60AT
Power voltage	100 to 240 VAC (+10%/-15%)
Operating ambient temperature	0 to 55°C (32 to 131°F) (no freezing)
Operating ambient humidity	5 to 95% RH (no condensation)
Operating environment	As little dust and corrosive gas as possible
Noise immunity	1500 V peak-to-peak or more, pulse duration 1 μs, 50 ns (based on noise simulator), IEC standard compliant (IEC61000-4-2/3/4/6)
Withstand voltage	1500 VAC for 1 minute, between power supply terminal and I/O terminals and between all external terminals and case
Insulation resistance	50 MΩ or more (500 VDC megger used to perform measurements between power terminal and input terminals, and between all external terminals and case)
Output power supply voltage	24 VDC (±10%; output capacity: 0.6 A)
Storage temperature	−25 to +75°C (−13 to +167°F)
Intermittent vibration (5 to 9 Hz)	Amplitude: 3.5 mm (0.14″)
Intermittent vibration (9 to 150 Hz)	Acceleration: 9.8 m/s² (32.2’/s²)
Continuous vibration (5 to 9 Hz)	Amplitude: 1.75 mm (0.07″)
Continuous vibration (9 to 150 Hz)	Acceleration: 4.9 m/s² (16.1’/s²)
Shock resistance	Acceleration: 150 m/s² (492.1’/s²), application time: 11 ms, three times in each of the X, Y, and Z directions
Operating altitude	2000 m (6561.7′)
Overvoltage category	AC: II, DC: I
Pollution degree	2
Calculation control method	Program storage method
I/O control method	Refresh method
Program language	Expanded ladder, KV Script, mnemonic
Number of instructions	335 types and 690 instructions
Instruction execution speed	Basic instruction: 50 ns minimum, Application instruction: 170 ns minimum
Program capacity	16k steps
Maximum number of attachable I/O units	8
Maximum number of I/O points	256 (excluding the base unit I/O)
Input relay/Output relay/Internal auxiliary relay	Total of 9600 points 1 bit (R000 to R59915)
Link relay	8192 points 1 bit (B0 to B1FFF)
Internal auxiliary relay	9600 points 1 bit (MR000 to MR59915)
Latch relay	3200 points 1 bit (LR000 to LR19915)
Control relay	1440 points 1 bit (CR000 to CR8915)
Timer	512 points 32 bit (T0 to T511)
Counter	256 points 32 bit (C0 to C255)
Data memory	32768 points 16 bit (DM0 to DM32767)
Link register	16384 points 16 bit (W0 to W3FFF)
Temporary memory	512 points 16 bit (TM0 to TM511)
High-speed counter	4 points (CTH0 to CTH3), 32-bit automatic reset counter
High-speed counter comparator	8 points (CTC0 to CTC7), 32 bits, two points per high-speed counter
Index register	12 points 32 bit (Z01 to Z12)
Control memory	9000 points 16 bit (CM0 to CM8999)
Positioning pulse output	4 axes, Maximum output frequency: 100 kHz
Base unit I/O	Input: 36 points, output: 24 points
Device comment	20000 When a maximum-length ladder program is written with no labels.
Label	28000 When a maximum-length ladder program is written with no device comments.
Program memory	Flash ROM can be rewritten 10000 times
Device	Nonvolatile RAM
Self-diagnosis function	CPU error, RAM error, and other problems
Relay number (General input)	R000 to R007, R100 to R203 (28 points)
Input mode	24 VDC input (open collector)
Maximum input voltage	26.4 VDC
Rated input voltage	24 VDC (General input: 5.3 mA)
Minimum ON voltage	19 VDC
Maximum OFF current	1.5 mA
Common method	General input: All points/1 common (1 terminal)
Circuit delay time	General input: OFF to ON: Max. 50 µs, High-speed input: OFF to ON: Max. 2 μs
