| Thông số | Giá trị |
|---|---|
| Model | KV-N40DT |
| Type | Temperature/Analog multi-input unit |
| Number of temperature input points | 4 ch |
| Input | Thermocoupler/Platinum temperature measuring resistor/Voltage and current |
| Thermocoupler Input Range | K: -270.0 to 1372.0°C-454 to 2502°FJ: -210.0 to 1200.0°C-346 to 2192°FT: -270.0 to 400.0°C-454 to 752°FE: -270.0 to 1000.0°C-454 to 1832°FN: -270.0 to 1300.0°C-454 to 2372°FR: -50.0 to 1768.0°C-58 to 3214°FS: -50.0 to 1768.0°C-58 to 3214°FB: 0.0 to 1820.0°C32 to 3308°FWRe5-26: 0.0 to 2315.0°C32 to 4199°F |
| Platinum temperature measuring resistor Input Range | Pt100: -200.0 to 850.0°C-328 to 1562°FJPt100: -200.0 to 600.0°C-328 to 1112°F |
| Voltage and current Input Range | Voltage:-10 to +10 V (0.5 mV 1/40000)0 V to 10 V (0.5 mV 1/20000)-5 V to +5 V (0.5 mV 1/20000)0 V to 5 V (0.5 mV 1/10000)1 V to 5 V (0.5 mV 1/8000)-100 mV to +100 mV (5 μV 1/40000)0 mV to 100 mV (5 μV 1/20000)Current:0 mA to 20 mA (2 μA 1/10000)4 mA to 20 mA (2 μA 1/8000) |
| Indicated accuracy | ±0.2% of F.S. (at 25°C ±5°C77°F ±9°F), ±0.4% of F.S. (at 0 to 50°C32 to 122°F) |
| Cold junction correction precision | ±1°C±1.8°F(during thermocouple input) |
| Input resistance | Voltage: 1 MΩ, Current: 250 Ω |
| Conversion speed | 50 ms/4 ch |
| Insulation mode | Between an input terminal and CPU: Photocoupler and transformer insulation,Between channels: Photocoupler and transformer insulation |
| Others | External cold junction correction, wire-breaking detection function, scaling function, average processing function (time average, average of the number of times, moving average, primary delay filter), special data offset function, alarm function, rate of change calculation, rate of change alarm function |
| Internal current consumption | 90 mA or less |
| Weight | Approx. 190 g |
PLC Keyence KV-N40DT (24 in/ 16 out transistor)
SKU: KV-N40DT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
5.500.000 ₫
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
Khu vực Miền Nam
Call: 03826 777 45 / Chat Zalo
Khu vực Miền Bắc
Call: 0383 167 778 / Chat Zalo
Khu vực Miền Trung
Call: 0388 895 669 / Chat Zalo
