| Thông số | Giá trị |
|---|---|
| Model | KV-N40AT |
| Power voltage | 100 to 240 VAC (+10%/-15%) |
| Operating ambient temperature | 0 to 55°C (32 to 131°F) (no freezing) |
| Operating ambient humidity | 5 to 95% RH (no condensation) |
| Operating environment | As little dust and corrosive gas as possible |
| Noise immunity | 1500 V peak-to-peak or more, pulse duration 1 μs, 50 ns (IEC standard compliant) |
| Withstand voltage | 1500 VAC for 1 minute, between power supply terminal and I/O terminals and between all external terminals and case |
| Insulation resistance | 50 MΩ or more |
| Output power supply voltage | 24 VDC (±10%; output capacity: 0.6 A) |
| Storage temperature | −25 to +75°C (−13 to +167°F) |
| Intermittent vibration frequency (5 to 9 Hz) | Amplitude: 3.5 mm (0.14″) |
| Intermittent vibration frequency (9 to 150 Hz) | Acceleration: 9.8 m/s² (32.2’/s²) |
| Continuous vibration frequency (5 to 9 Hz) | Amplitude: 1.75 mm (0.07″) |
| Continuous vibration frequency (9 to 150 Hz) | Acceleration: 4.9 m/s² (16.1’/s²) |
| Shock resistance | Acceleration: 150 m/s² (492.1’/s²), application time: 11 ms, three times in each of the X, Y, and Z directions |
| Operating altitude | 2000 m (6561.7′) |
| Overvoltage category | AC: II, DC: I |
| Pollution degree | 2 |
| Calculation control method | Program storage method |
| I/O control method | Refresh method |
| Program language | Expanded ladder, KV Script, mnemonic |
| Number of instructions | 335 types and 690 instructions |
| Instruction execution speed | Basic instruction: 50 ns minimum, Application instruction: 170 ns minimum |
| Program capacity | 16k steps |
| Maximum number of attachable I/O units | 8 |
| Maximum number of I/O points | 256 (excluding the base unit I/O) |
| Input relay/Output relay/Internal auxiliary relay | Total of 9600 points 1 bit (R000 to R59915) |
| Link relay | 8192 points 1 bit (B0 to B1FFF) |
| Internal auxiliary relay | 9600 points 1 bit (MR000 to MR59915) |
| Latch relay | 3200 points 1 bit (LR000 to LR19915) |
| Control relay | 1440 points 1 bit (CR000 to CR8915) |
| Timer | 512 points 32 bit (T0 to T511) |
| Counter | 256 points 32 bit (C0 to C255) |
| Data memory | 32768 points 16 bit (DM0 to DM32767) |
| Link register | 16384 points 16 bit (W0 to W3FFF) |
| Temporary memory | 512 points 16 bit (TM0 to TM511) |
| High-speed counter | 3 points (CTH0 to CTH2), 32-bit automatic reset counter |
| High-speed counter comparator | 6 points (CTC0 to CTC5), 32 bits, two points per high-speed counter |
| Index register | 12 points 32 bit (Z01 to Z12) |
| Control memory | 9000 points 16 bit (CM0 to CM8999) |
| Positioning pulse output | 3 axes, Maximum output frequency: 100 kHz |
| Base unit I/O | Input: 24 points, output: 16 points, Input common: 1 point, Output common: 2 points |
| Device comment | 20000 when a maximum-length ladder program is written with no labels |
| Label | 28000 when a maximum-length ladder program is written with no device comments |
| Program memory | Flash ROM can be rewritten 10000 times |
| Device | Nonvolatile RAM |
| Self-diagnosis function | CPU error, RAM error, and other problems |
| Relay number (General input) | R000 to R007, R014 to R107 (18 points) |
| Input mode | 24 VDC input (open collector) |
| Maximum input voltage | 26.4 VDC |
| Rated input voltage | 24 VDC |
| Minimum ON voltage | 19 VDC |
| Maximum OFF current | 1.5 mA |
| Common method (General input) | All points/1 common |
| Circuit delay time (General input) | OFF to ON: Max. 30 μs, ON to OFF: Max. 50 μs |
| Input time constant | Normal: 10 ms, When the HSP instruction is used: 10 μs |
| Response frequency (High-speed A-phase and B-phase input) | Single phase: 100 kHz, phase difference: 50 kHz |
| Relay number (General output) | R506 to R515 (10 points) |
| Output mode | MOSFET |
| Rated load | 30 VDC, 0.5 A |
| Maximum OFF voltage | 30 VDC |
| Leakage current at OFF | 100 μA or less |
| Residual voltage at ON | 0.8 VDC or less (with 0.5 A output) |
| Common method (Output) | 8 to 10 points/1 common |
| ON/OFF response time (General output) | OFF to ON: 100 μs, ON to OFF: 200 μs |
| Overcurrent protection | Protection provided for each common |
| Output frequency | High-speed output: 100 kHz |
| RS-232C Baud rate | 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps |
| RS-232C Transmission method | Full duplex |
| RS-232C Data format (Start bit) | 1 bit |
| RS-232C Data bits | 7 bits, 8 bits |
| RS-232C Stop bits | 1 bit, 2 bits |
| RS-232C Error detection | Parity: Even, odd, none |
| Transmission distance | 15 m (49.2′) |
| Transmission units | 1 |
| Indication | SD (green), RD (red) |
| Internal current consumption | 82 VA |
| Weight | Approx. 620 g |
PLC Keyence KV-N40AT (24 in/ 16 out transistor)
SKU: KV-N40AT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
5.500.000 ₫
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
