| Thông số | Giá trị |
|---|---|
| Model | KV-N24DT |
| Power voltage | 24 VDC (+10%/-15%) |
| Operating ambient temperature | 0 to 55°C (32 to 131°F) (no freezing) |
| Operating ambient humidity | 5 to 95% RH (no condensation) |
| Operating environment | As little dust and corrosive gas as possible |
| Noise immunity | 1500 V peak-to-peak or more, pulse duration 1 μs, 50 ns (IEC standard compliant) |
| Withstand voltage | 1500 VAC for 1 minute, between power supply terminal and I/O terminals |
| Insulation resistance | 50 MΩ or more (500 VDC megger used) |
| Storage temperature | −25 to +75°C (−13 to +167°F) |
| Intermittent vibration (Frequency: 5 to 9 Hz) | Amplitude: 3.5 mm (0.14″) |
| Intermittent vibration (Frequency: 9 to 150 Hz) | Acceleration: 9.8 m/s² (32.2’/s²) |
| Continuous vibration (Frequency: 5 to 9 Hz) | Amplitude: 1.75 mm (0.07″) |
| Continuous vibration (Frequency: 9 to 150 Hz) | Acceleration: 4.9 m/s² (16.1’/s²) |
| Shock resistance | Acceleration: 150 m/s² (492.1’/s²), application time: 11 ms, three times in X, Y, Z directions |
| Operating altitude | 2000 m (6561.7′) |
| Overvoltage category | AC: II, DC: I |
| Pollution degree | 2 |
| Calculation control method | Program storage method |
| I/O control method | Refresh method |
| Program language | Expanded ladder, KV Script, mnemonic |
| Number of instructions | Total: 335 types and 690 instructions |
| Instruction execution speed | Basic instruction: 50 ns minimum |
| Program capacity | 8k steps |
| Maximum number of attachable I/O units | 8 |
| Maximum number of I/O points | 256 (excluding base unit I/O) |
| Input relay/Output relay/Internal auxiliary relay | Total of 9600 points 1 bit (R000 to R59915) |
| Internal auxiliary relay | MR: 9600 points 1 bit (MR000 to MR59915) |
| Latch relay | LR: 3200 points 1 bit (LR000 to LR19915) |
| Timer | T: 512 points 32 bit (T0 to T511) |
| Data memory | DM: 32768 points 16 bit (DM0 to DM32767) |
| Link register | W: 16384 points 16 bit (W0 to W3FFF) |
| Temporary memory | TM: 512 points 16 bit (TM0 to TM511) |
| High-speed counter | CTH: 2 points (CTH0 to CTH1) |
| High-speed counter comparator | CTC: 4 points (CTC0 to CTC3) |
| Index register | Z: 12 points 32 bit (Z01 to Z12) |
| Control memory | CM: 9000 points 16 bit (CM0 to CM8999) |
| Positioning pulse output | 2 axes Maximum output frequency: 100 kHz |
| Base unit I/O | Input: 14 points, Output: 10 points |
| Device comment | 20000 |
| Label | 28000 |
| Program memory | Flash ROM, 10000 rewrites |
| Self-diagnosis function | CPU error, RAM error, other problems |
| Input mode | 24 VDC input (open collector) |
| Relay number | General input: R000 to R003, R008 to R013 |
| Input mode | 24 VDC input (open collector) |
| Output mode | MOSFET |
| Weight | Approx. 390 g |
PLC Keyence KV-N24DT (14 in/ 10 out transistor)
SKU: KV-N24DT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
4.500.000 ₫
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
