| Thông số | Giá trị |
|---|---|
| Model | KV-N24DR |
| Power voltage | 24 VDC (+10%/-15%) |
| Operating ambient temperature | 0 to 55°C (32 to 131°F) (no freezing) |
| Operating ambient humidity | 5 to 95% RH (no condensation) |
| Operating environment | As little dust and corrosive gas as possible |
| Noise immunity | 1500 V peak-to-peak or more, pulse duration 1 μs, 50 ns (IEC standard compliant) |
| Withstand voltage | 1500 VAC for 1 minute, between power supply terminal and I/O terminals |
| Insulation resistance | 50 MΩ or more (500 VDC megger used for measurements) |
| Storage temperature | −25 to +75°C (−13 to +167°F) |
| Vibration resistance (Intermittent vibration – 5 to 9 Hz) | Amplitude: 3.5 mm (0.14″) |
| Vibration resistance (Intermittent vibration – 9 to 150 Hz) | Acceleration: 9.8 m/s² (32.2’/s²) |
| Vibration resistance (Continuous vibration – 5 to 9 Hz) | Amplitude: 1.75 mm (0.07″) |
| Vibration resistance (Continuous vibration – 9 to 150 Hz) | Acceleration: 4.9 m/s² (16.1’/s²) |
| Shock resistance | Acceleration: 150 m/s² (492.1’/s²), application time: 11 ms, three times in each direction |
| Operating altitude | 2000 m (6561.7′) |
| Overvoltage category | AC: II, DC: I |
| Pollution degree | 2 |
| Calculation control method | Program storage method |
| I/O control method | Refresh method |
| Program language | Expanded ladder, KV Script, mnemonic |
| Number of instructions | 335 types and 690 instructions |
| Instruction execution speed (Basic instruction) | 50 ns minimum |
| Program capacity | 8k steps |
| Maximum number of attachable I/O units | 8 |
| Maximum number of I/O points | 256 (excluding the base unit I/O) |
| Input relay/Output relay/Internal auxiliary relay | Total of 9600 points 1 bit (R000 to R59915) |
| High-speed counter | 2 points (CTH0 to CTH1), 32-bit automatic reset counter |
| Self-diagnosis function | CPU error, RAM error, and other problems |
| Input mode | 24 VDC input (open collector) |
| Maximum input voltage | 26.4 VDC |
| Rated input voltage | 24 VDC (General input: 5.3 mA, High-speed A-phase and B-phase input: 6.5 mA) |
| Minimum ON voltage | 19 VDC |
| Maximum OFF current | 1.5 mA |
| Output mode | Relay |
| Rated load | 250 VAC/30 VDC, 2 A |
| Relay life (Electrical) | 100000 cycles or more (20 cycles/minute) |
| Relay life (Mechanical) | 20000000 cycles or more |
| Built-in serial port (Communication standard) | RS-232C |
| Transmission specifications (Baud rate) | 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps |
| Transmission method | Full duplex |
| Transmission distance | 15 m (49.2′) |
| Internal current consumption | 190 mA |
| Weight | Approx. 420 g |
PLC Keyence KV-N24DR (14 in/ 10 out relay)
SKU: KV-N24DR
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
4.500.000 ₫
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
