PLC Keyence KV-N24AT (14 in/ 10 out transistor)

PLC Keyence KV-N24AT (14 in/ 10 out transistor)

SKU: KV-N24AT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

4.500.000 ₫

Báo giá
SKU: KV-N24AT Danh mục: Thương hiệu:
Thông số Giá trị
Model KV-N24AT
Power voltage 100 to 240 VAC (+10%/-15%)
Operating ambient temperature 0 to 55°C (32 to 131°F) (no freezing)
Operating ambient humidity 5 to 95% RH (no condensation)
Operating environment As little dust and corrosive gas as possible
Noise immunity 1500 V peak-to-peak or more, pulse duration 1 μs, 50 ns (based on noise simulator), IEC standard compliant (IEC61000-4-2/3/4/6)
Withstand voltage 1500 VAC for 1 minute, between power supply terminal and I/O terminals and between all external terminals and case
Insulation resistance 50 MΩ or more (500 VDC megger used to perform measurements between power terminal and input terminals, and between all external terminals and case)
Output power supply voltage 24 VDC (±10%; output capacity: 0.6 A)
Storage temperature −25 to +75°C (−13 to +167°F)
Vibration resistance (Intermittent vibration – 5 to 9 Hz) Amplitude: 3.5 mm (0.14″)
Vibration resistance (Intermittent vibration – 9 to 150 Hz) Acceleration: 9.8 m/s² (32.2’/s²)
Vibration resistance (Continuous vibration – 5 to 9 Hz) Amplitude: 1.75 mm (0.07″)
Vibration resistance (Continuous vibration – 9 to 150 Hz) Acceleration: 4.9 m/s² (16.1’/s²)
Shock resistance Acceleration: 150 m/s² (492.1’/s²), application time: 11 ms, three times in each of the X, Y, and Z directions
Operating altitude 2000 m (6561.7′)
Overvoltage category AC: II, DC: I
Pollution degree 2
Calculation control method Program storage method
I/O control method Refresh method
Program language Expanded ladder, KV Script, mnemonic
Number of instructions Basic instruction: 81 types and 182 instructions, Application instruction: 39 types and 56 instructions, Calculation instruction: 123 types and 311 instructions, Expansion instruction: 92 types and 141 instructions, Total: 335 types and 690 instructions
Instruction execution speed Basic instruction: 50 ns minimum, Application instruction: 170 ns minimum
Program capacity 8k steps
Maximum number of attachable I/O units 8
Maximum number of I/O points 256 (excluding the base unit I/O)
Input relay/Output relay/Internal auxiliary relay Total of 9600 points 1 bit (R000 to R59915)
Link relay 8192 points 1 bit (B0 to B1FFF)
Internal auxiliary relay 9600 points 1 bit (MR000 to MR59915)
Latch relay 3200 points 1 bit (LR000 to LR19915)
Control relay 1440 points 1 bit (CR000 to CR8915)
Timer 512 points 32 bit (T0 to T511)
Counter 256 points 32 bit (C0 to C255)
Data memory 32768 points 16 bit (DM0 to DM32767)
Link register 16384 points 16 bit (W0 to W3FFF)
Temporary memory 512 points 16 bit (TM0 to TM511)
High-speed counter 2 points (CTH0 to CTH1) 32-bit automatic reset counter (Input response: 100 kHz per single phase, 50 kHz per phase difference)
High-speed counter comparator 4 points (CTC0 to CTC3), 32 bits, two points per high-speed counter
Index register 12 points 32 bit (Z01 to Z12)
Control memory 9000 points 16 bit (CM0 to CM8999)
Positioning pulse output 2 axes Maximum output frequency: 100 kHz
Base unit I/O Input: 14 points, output: 10 points Input common: 1 point Output common: 1 point
Number of comments and labels that can be stored in the main unit (Device comment) 20000 When a maximum-length ladder program is written with no labels.
Number of comments and labels that can be stored in the main unit (Label) 28000 When a maximum-length ladder program is written with no device comments.
Power off hold function (Program memory) Flash ROM can be rewritten 10000 times
Power off hold function (Device) Nonvolatile RAM
Self-diagnosis function CPU error, RAM error, and other problems
Relay number (General input) R000 to R003, R008 to R013 (10 points)
Relay number (High-speed A-phase and B-phase input) R004 to R007 (2 channels, 4 points in total)
Input mode 24 VDC input (open collector)
Maximum input voltage 26.4 VDC
Rated input voltage 24 VDC (General input: 5.3 mA, High-speed A-phase and B-phase input: 6.5 mA)
Minimum ON voltage 19 VDC
Maximum OFF current 1.5 mA
Common method General input: All points/1 common (1 terminal), High-speed A-phase and B-phase input: Shared common for all points (shared with general input)
Circuit delay time (General input) OFF to ON: Max. 30 μs (Typ. 3.5 μs), ON to OFF: Max. 50 μs (Typ. 15 μs)
Circuit delay time (High-speed A-phase and B-phase input) OFF to ON: Max. 2 μs (Typ. 1.1 μs), ON to OFF: Max. 2 μs (Typ. 0.3 μs)
Response frequency (High-speed A-phase and B-phase input) Single phase: 100 kHz, phase difference: 50 kHz, 24 V ±10%, Duty 50%
Relay number (General output) R504 to R509 (6 points), High-speed output: R500 to R503 (4 points)
Output mode MOSFET (N-ch) output for the sink output type
Rated load 30 VDC, 0.5 A
Maximum OFF voltage 30 VDC
Leakage current at OFF 100 μA or less
Residual voltage at ON 1.5 V or less (at 0.5 A)
Response time OFF to ON: Max. 2 ms, ON to OFF: Max. 2 ms
