Name: PLC Keyence KV-N14AR (8 in/ 6 out relay)
Brand: Keyence
SKU: KV-N14AR
Availability: InStock

Thông số	Giá trị
Model	KV-N14AR
Power voltage	100 to 240 VAC (+10%/-15%)
Operating ambient temperature	0 to 55°C (32 to 131°F) (no freezing)
Operating ambient humidity	5 to 95% RH (no condensation)
Operating environment	As little dust and corrosive gas as possible
Noise immunity	1500 V peak-to-peak or more, pulse duration 1 μs, 50 ns (based on noise simulator), IEC standard compliant (IEC61000-4-2/3/4/6)
Withstand voltage	1500 VAC for 1 minute, between power supply terminal and I/O terminals and between all external terminals and case
Insulation resistance	50 MΩ or more (500 VDC megger used to perform measurements between power terminal and input terminals, and between all external terminals and case)
Output power supply voltage	24 VDC (±10%; output capacity: 0.6 A)
Storage temperature	−25 to +75°C (−13 to +167°F)
Intermittent vibration	Frequency: 5 to 9 Hz, Amplitude: 3.5 mm (0.14″)
Continuous vibration	Frequency: 5 to 9 Hz, Amplitude: 1.75 mm (0.07″)
Shock resistance	Acceleration: 150 m/s² (492.1’/s²), application time: 11 ms, three times in each of the X, Y, and Z directions
Operating altitude	2000 m (6561.7′)
Overvoltage category	AC: II, DC: I
Pollution degree	2
Program capacity	8k steps
Maximum number of attachable I/O units	3
Maximum number of I/O points	128 (excluding the base unit I/O)
Input relay/Output relay/Internal auxiliary relay	Total of 9600 points 1 bit (R000 to R59915)
Link relay	8192 points 1 bit (B0 to B1FFF)
Internal auxiliary relay	9600 points 1 bit (MR000 to MR59915)
Latch relay	3200 points 1 bit (LR000 to LR19915)
Control relay	1440 points 1 bit (CR000 to CR8915)
Timer	512 points 32 bit (T0 to T511)
Counter	256 points 32 bit (C0 to C255)
Data memory	32768 points 16 bit (DM0 to DM32767)
Link register	16384 points 16 bit (W0 to W3FFF)
Temporary memory	512 points 16 bit (TM0 to TM511)
High-speed counter	2 points (CTH0 to CTH1), 32-bit automatic reset counter
High-speed counter comparator	4 points (CTC0 to CTC3), 32 bits, two points per high-speed counter
Index register	12 points 32 bit (Z01 to Z12)
Control memory	9000 points 16 bit (CM0 to CM8999)
Base unit I/O	Input: 8 points, output: 6 points, Input common: 1 point, Output common: 4 points
Device comment	10000 when a maximum-length ladder program is written with no labels.
Label	14000 when a maximum-length ladder program is written with no device comments.
Program memory	Flash ROM can be rewritten 10000 times
Device	Nonvolatile RAM
Self-diagnosis function	CPU error, RAM error, and other problems
Relay number (General input)	R000 to R003 (4 points)
Input mode	24 VDC input (open collector)
Maximum input voltage	26.4 VDC
Rated input voltage	24 VDC (General input: 5.3 mA, High-speed A-phase and B-phase input: 6.5 mA)
Common method	General input: All points/1 common (1 terminal), High-speed A-phase and B-phase input: Shared common for all points (shared with general input)
Circuit delay time	General input: OFF to ON: Max. 30 μs (Typ. 3.5 μs), ON to OFF: Max. 50 μs (Typ. 15 μs), High-speed A-phase and B-phase input: OFF to ON: Max. 2 μs (Typ. 1.1 μs), ON to OFF: Max. 2 μs (Typ. 0.3 μs)
Input time constant	Normal: 10 ms, When the HSP instruction is used: 10 μs
Response frequency	(High-speed A-phase and B-phase input) Single phase: 100 kHz, phase difference: 50 kHz, 24 V ±10%, Duty 50%
Relay number (Output)	R500 to R505 (6 points)
Output mode	Relay
Rated load	250 VAC/30 VDC, 2 A
Common method	2 to 4 points/1 common
ON/OFF response time	10 ms or less
ON resistance	50 mΩ or less
Minimum applicable load	100 μA/100 mVDC
Relay life	Electrical: 100000 cycles or more (20 cycles/minute), Mechanical: 20000000 cycles or more
Relay replacement	Impossible
Built-in serial port interface	RS-232C
Transmission distance	15 m (49.2′)
Transmission baud rate	1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
Transmission method	Full duplex
Data format	Start bit: 1 bit, Data bits: 7 bits, 8 bits, Stop bits: 1 bit, 2 bits
Error detection	Parity: Even, odd, none
Indication	SD (green), RD (red)
Internal current consumption	76 VA
Weight	Approx. 430 g
