Name: PLC Keyence KV-700
Brand: Keyence
SKU: KV-700
Availability: InStock

Thông số	Giá trị
Model	KV-700
Type	CPU Unit
Power Voltage	24 VDC (±10%)
Operating Ambient Temperature	0 to 50 °C (no freezing)12
Relative Humidity	35 to 85 % RH (no condensation)*1
Storage Temperature	-20 to +70 °C*1
Operating Environment	Best in an environment with minimal dust and corrosive gases
Altitude	2,000 m or less
Noise Immunity	1,500 Vp-p or more, pulse width 1 µs, 50 ns (based on noise simulator), Conforms to IEC standards (IEC61000-4-2/3/4/6)
Withstand Voltage	1,500 VAC for 1 minute between power supply terminal and I/O terminal or external terminal and enclosure
Insulation Resistance	Over 50 MΩ (measured between power supply terminal and I/O terminal or external terminal and enclosure with a 500 V DC megohmmeter)
Overvoltage Category	II (When using KV-U7)
Pollution Degree	2
Intermittent Vibration (Shock Resistance)	Frequency 10 to 57 Hz, Half amplitude: 0.075 mm3Frequency 57 to 150 Hz, Acceleration: 9.8 m/s23
Continuous Vibration (Shock Resistance)	Frequency 10 to 57 Hz, Half amplitude: 0.035 mm3Frequency 57 to 150 Hz, Acceleration: 4.9 m/s23
Operation Control Method	Program storage method
I/O Control Method	Refresh method
Programming Language	Expanded Ladder, Mnemonic
Number of Instructions	Basic instructions: 67 classes, 122 instructionsApplication instructions: 19 classes, 19 instructionsArithmetic operation instructions: 64 classes, 294 instructionsExpansion instructions: 31 classes, 48 instructionsTotal: 181 classes, 483 instructions
Instruction Execution Speed	Basic instructions: 100 ns minimumApplication instructions: 100 ns minimum
Program Capacity	Approx. 16k steps (Approx. 32k steps with memory expansion)
Maximum Number of Installable Units	16 units (48 units when expansion units are connected)
Maximum Number of I/O Points	Max. 3,086 points when expanded (KV-EB1S/KV-EB1R: when 2 units are expanded, using 64-point I/O units)
Input Relay R (Bit Devices)	Total 9,530 points 1 bit
Output Relay R (Bit Devices)	Total 9,530 points 1 bit
Internal Auxiliary Relay R (Bit Devices)	Total 9,530 points 1 bit
Control Relay CR (Bit Devices)	640 points 1 bit
Timer T (Word Devices)	Total 512 points 32 bit
Counter C (Word Devices)	Total 512 points 32 bit
Data Memory DM (Word Devices)	20,000 points 16 bit (40,000 points 16 bit with memory expansion)
Temporary Data Memory TM (Word Devices)	512 points 16 bit
High-Speed Counter CTH (Word Devices)	2 points 32 bit
High-Speed Counter Comparator CTC (Word Devices)	4 points 32-bit (uses 2 high-speed counter points)
Control Memory CM (Word Devices)	4,000 points 16 bit
Positioning Pulse Output	2 points (100 kHz max. output frequency)
CPU Unit I/O	Inputs: 10 points, Outputs: 4 points
Program Memory (Power Off Hold Function)	Flash memory rewritable 100,000 times
Devices (Power Off Hold Function)	Battery backup for 5 years (operating ambient temperature 25 °C, during power off hold mode)*4
Self-Diagnosis Function	CPU error, RAM error, others
Internal Current Consumption	CPU unit: 160 mA or lessExpansion unit: KV-EB1S 15 mA or less, KV-EB1R 25 mA or less (Excluding drive current for input circuit)
Weight	CPU unit: KV-700 Approx. 240 g, Memory expansion for KV-700 (OP-42138) Approx. 10 gTerminal block: Approx. 30 gStart block for KV-1000/700: Approx. 30 gExpansion unit: KV-EB1S Approx. 90 g, KV-EB1R Approx. 115 g
