| Thông số | Giá trị |
|---|---|
| Model | KV-40DT |
| Type | DC power supply type base unit |
| Input power supply voltage (Base unit) | 24 VDC (+10%, -20%) |
| Allowable instantaneous outage time | Less than 2 ms |
| Internal current consumption (Base unit) | 120mA or less |
| Internal current consumption (Expansion unit – KV-E4X) | 20mA or less |
| Internal current consumption (Expansion unit – KV-E8X) | 25mA or less |
| Internal current consumption (Expansion unit – KV-E16X) | 35mA or less |
| Internal current consumption (Expansion unit – KV-E4T) | 25mA or less |
| Internal current consumption (Expansion unit – KV-EST(P)) | 40mA or less |
| Internal current consumption (Expansion unit – KV-E16T) | 60mA or less |
| Internal current consumption (Expansion unit – KV-E4R) | 40mA or less |
| Internal current consumption (Expansion unit – KV-E8R) | 70mA or less |
| Internal current consumption (Expansion unit – KV-E16TP) | 70mA or less |
| Internal current consumption (Expansion unit – KV-E4XT(P)) | 30mA or less |
| Internal current consumption (Expansion unit – KV-E4XR) | 45mA or less |
| Internal current consumption (Expansion unit – KV-E16R) | 110mA or less |
| Internal current consumption (Operator panel – KV-D20) | 60 mA or less |
| Internal current consumption (KL link adapter – KL-N10V) | 35 mA or less |
| Internal current consumption (Programming console – KZ-P3) | 65 mA or less |
| Operating temperature range | 0 to 50°C (32 to 122°F) (no freezing), 0 to 45°C (32 to 113°F) (KZ-P3) |
| Operating ambient humidity | 35 to 85% RH (no condensation) |
| Ambient temperature for storage | -20 to 70°C (-4 to 158°F) (no freezing) |
| Withstand voltage | 1,500 VAC for 1 minute |
| Noise resistance | 1,500 Vp-p or more |
| Shock resistance | Conforms to JIS C 0041, 150 m/s² (15G), operating time: 11 ms |
| Base unit weight | Approx 280g |
| Insulation resistance | 50 MΩ or more |
| Ambient operating atmosphere | Minimal amount of dust and corrosive gas present |
| Expansion unit weight (KV-E4X) | Approx 80 g |
| Expansion unit weight (KV-E8X) | Approx 100 g |
| Expansion unit weight (KV-E16X) | Approx 130 g |
| Expansion unit weight (KV-E4T) | Approx 80 g |
| Expansion unit weight (KV-EST(P)) | Approx 100 g |
| Expansion unit weight (KV-E16T(P)) | Approx 130 g |
| Expansion unit weight (KV-E4R) | Approx 100 g |
| Expansion unit weight (KV-E8R) | Approx 130 g |
| Expansion unit weight (KV-E16R) | Approx 190 g |
| Expansion unit weight (KV-E4XT(P)) | Approx 100 g |
| Expansion unit weight (KV-E4XR) | Approx 120 g |
| Other weight (KZ-P3) | Approx 230g |
| Other weight (KV-D20) | Approx 160g |
| Other weight (KL-N10V) | Approx 80g |
| Vibration resistance (Intermittent – 10 to 57 Hz) | Amplitude: 0.075 mm |
| Vibration resistance (Intermittent – 57 to 150 Hz) | Acceleration: 9.8 m/s² |
| Vibration resistance (Continuous – 10 to 57 Hz) | Amplitude: 0.035 mm |
| Vibration resistance (Continuous – 57 to 150 Hz) | Acceleration: 4.9 m/s² |
PLC Keyence KV-40DT (24 in/ 16 out transistor)
SKU: KV-40DT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
7.500.000 ₫
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
