| Thông số | Giá trị |
|---|---|
| Model | KV-1000 |
| Type | CPU Unit |
| Power Voltage | 24 VDC (±10%) |
| Operating Temperature | 0 to +50°C (no freezing)*1,*2 |
| Operating Humidity | 35–85% RH (non-condensing)*1 |
| Storage Temperature | -20 to +70°C*3 |
| Operating Environment | Dust-free, non-corrosive gases |
| Altitude | ≤2,000 m |
| Noise Immunity | 1,500 Vp-p (IEC61000-4-2/3/4/6 compliant) |
| Withstand Voltage | 1,500 VAC for 1 minute (between power/I/O terminals) |
| Insulation Resistance | ≥50 MΩ (500 VDC megger test) |
| Shock Resistance | 150 m/s² for 11 ms (X/Y/Z directions) |
| Vibration Resistance | Intermittent:– 10–57 Hz: 0.075 mm amplitude*4– 57–150 Hz: 9.8 m/s²*4Continuous:– 10–11 Hz: 0.035 mm*4– 57–150 Hz: 4.9 m/s²*4 |
| Overvoltage Category | II (with KV-U7) |
| Pollution Degree | 2 |
| Control Method | Stored program with I/O refresh |
| Programming Language | Ladder logic, KV Script, mnemonics |
| Instructions | – Basic: 68 types (151 instructions)– Applied: 35 types (36 instructions)– Arithmetic: 83 types (185 instructions)– Extended: 74 types (106 instructions)Total: 260 types, 478 instructions |
| Execution Speed | Basic/Applied instructions: 25 ns min. |
| Program Capacity | ~160k steps |
| Max I/O Points | 3,096 points (with 64-point expansions) |
| Bit Devices | – Input/Output Relays (R): 9,536 points– Internal Relays (MR): 16,000 points– Latch Relays (LR): 16,000 points– Control Relays (CR): 640 points |
| Word Devices | – Timers/Counters: 4,000 points (32-bit)– Data Memory (DM/EM): 65,535 points (16-bit)– Expansion Memory (FM): 32,767 points– High-Speed Counters: 2–4 points (32-bit) |
| Positioning Output | 2 points (100 kHz max frequency) |
| Power Backup | – Program Memory: Flash ROM (100k writes)– Device Retention: 5 years (25°C)*5 |
| Weight | – CPU Unit: ~290 g– Expansion Units: 90–115 g |
PLC Keyence KV-1000
SKU: KV-1000
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
6.200.000 ₫
