HMI Proface PFXGP3300TADCA 5.7 inch

HMI Proface PFXGP3300TADCA 5.7 inch

SKU: PFXGP3300TADCA
Nhà sản xuất: Proface
Chất lượng: Mới 100%
Chứng từ: Hóa đơn VAT

Báo giá
Mã sản phẩm: PFXGP3300TADCA Danh mục: Thương hiệu:
Display Type TFT Color LCD
Display Size 5.7″
Resolution 320 x 240 pixels (QVGA)
Dot pitch W0.36 X H0.36mm [W0.01 X H0.01in.]
Effective Display Area W115.2 X H86.4mm [W4.54 X H3.40in.]
Display Colors 65,536 Colors (No blink)/16,384 Colors (Blink)
Backlight CCFL (User nonreplaceable parts, return system to distributor.)
Brightness Control 8 Levels (Adjusted with the touch panel)
Contrast Control Not applicable
Backlight Service Life 50,000 hrs. or more (continuous operation at 25°C before backlight brightness decreases to 50% or backlight starts to blink)
Language Fonts Japanese: 6,962 (JIS Standards 1 & 2) (including 607 non-kanji characters), ANK: 158 (Korean fonts, Simplified Chinese and Traditional Chinese fonts are downloadable.
Character Sizes Standard font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts, Stroke font: 6 to 127 pixel fonts, Image font: 8 to 72 pixel fonts
Font Sizes Standard font: Width can be expanded up to 8 times., Height can be expanded up to 8 times.
8 x 16 dots 40 char. X 15 rows
16 x 16 dots 20 char. X 15 rows
32 x 32 dots 10 char. X 7 rows
8 x 8 dots 40 char. X 30 rows
Program Area FLASH EPROM 132 KB
Number of Step Equivalent to 15,000 steps*1
Variable Area SRAM 64 KB (uses lithium battery)*2
Application Memory FLASH EPROM 6 MB*3
Data Backup SRAM 320KB (uses lithium battery)*4
Clock Accuracy 65 sec/month (deviation at room temperature and power is OFF)*5
Touch Panel Type Resistive Film (analog)
Touch Panel Resolution 1,024 X 1,024
Touch Panel Service Life 1,000,000 times or more
Serial (COM1) RS-232C/422/485, Asynchronous Transmission, Data Length: 7 or 8 bit, Parity: none, Even or Odd, Stop Bit: 1 or 2 bit, Data Transmission Speed: 2,400 bps to 115.2 kbps, Connector: D-Sub9 (plug)
Serial (COM2) RS-422/485, Asynchronous Transmission, Data Length: 7 or 8 bit, Parity: none, Even or Odd, Stop Bit: 1 or 2 bit, Data Transmission Speed: 2,400 bps to 115.2 kbps, 187.5kbps (MPI), Connector: D-Sub9 (socket)
Ethernet (LAN) IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX, Connector: Modular jack (RJ-45) x 1
Expansion Unit 1 Communication Expansion Unit X 1
USB (TYPE-A) Conforms to USB1.1. (TYPE-A conn.) X 1, Power Supply Voltage: DC5V±5%, Output Current: 500mA (max.), Communication Distance: 5m (max.)
CF Card Compact Flash CF Card Slot (TYPE-II) X 1
CANopen Type Bit variable input: 512 points, Bit variable output: 512 points, Integer variable input: 128 points, Integer variable output: 128 points, Connector: D-Sub9 (plug)*6
Rated Input Voltage DC 24V
Input Voltage Limits DC 19.2 to 28.8V
Allowable Voltage Drop 5 ms or less
Power Consumption 26 W or less
In-Rush Current 30 A or less
Voltage Endurance AC 1,000V, 20 mA for 1 minute (between charging and FG terminals)
Insulation Resistance DC500V 10MΩ (min.), (between charging and FG terminals)
Surrounding Air Temperature 0 to 50 °C (32 to 122 °F)
Storage Temperature -20 to 60 °C (-4 to 140 °F)
Ambient Humidity 10 to 90% RH (Wet bulb temperature: 39°C max. – no condensation.)
Storage Humidity 10 to 90% RH (Wet bulb temperature: 39°C max. – no condensation.)
Dust 0.1 mg/m³ or less (non-conductive levels)
Pollution Degree For use in Pollution Degree 2 environment
Atmosphere Free of corrosive gases
Air Pressure (altitude range) 800 to 1,114 hPa (2,000 m [6,561ft.] above sea level or less)
Vibration Resistance IEC/EN61131-2 compliant, 5 to 9Hz Single amplitude 3.5mm [0.14in.], 9 to 150Hz Fixed acceleration: 9.8m/s², X,Y,Z directions for 10 cycles (100 minutes)
Concussion Resistance IEC/EN61131-2 compliant, 147m/s² X,Y,Z directions for 3 times
Noise Immunity Noise Voltage: 1,000Vp-p, Pulse Duration: 1µs, Rise Time: 1ns, (via noise simulator)
Electrostatic Discharge Immunity Contact Discharge Method: 6kV (IEC/EN61000-4-2 Level 3)
Grounding Functional grounding: Grounding resistance of 100Ω, 2mm² or thicker wire, or your country’s applicable standard. (Same for FG and SG terminals)
Structure Equivalent to IP65f NEMA
250 TYPE 4X/13 (Front surface of embedded panel)*7
Installation Configuration Embedded panel
Cooling Method Natural air circulation
Weight Approx. 1.2 kg [2.6 lb] or less (display unit only)
External Dimensions W167.5 X H135 X D59.5mm, [W6.59 X H5.31 X D2.34in.]
Panel Cut Dimensions W156.0 X H123.5mm [W6.14 X H4.86in.], Panel thickness area: 1.6 to 5.0mm [0.06 to 0.20in.]*8

Thông tin bổ sung

Thương hiệu

Proface
Xuất xứ

Pháp
Thời gian bảo hành

1 Năm
Kích thước màn hình

5.7 inch
Series
