HMI Weintek MT8104X 10.4 inch 24VDC

SKU: MT8104X
Nhà sản xuất: Weintek
Chất lượng: Mới 100%
Chứng từ: Hóa đơn VAT

Mã: MT8104X Danh mục: HMI, HMI Weintek

Hardware Specification
Display	10.4″ TFT
Brightness	400 cd/m2
Color	65536 colors
Contrast Ratio	300:01:00
Resolution (WxH dots)	640 x 480
Back light	CCFLx2
CCFL life time	40,000 hr. min.
Touch panel	4 wires resistive type
Touch Accuracy	2mm
Surface Hardness	4H
I/O port	COM1 (RS-232/RS-485 2W/4W), COM2(RS232),COM3(RS-232/RS-4852W),1 Ethernet port (10/100
	Base-T),SD CARD SLOT, PS/2 Port Connector
USB Host	2 USB Host port
Audio	1 x Audio Line Out, 1 x MIC In
Processor	AMD Geode& x2122; LX800/500MHz core processor
Storage	256MB D.O.M
DRAM	256MB on board DDR-400MHz SDRAM
CompactFlash card slot	N/A
RTC	Built-in (CR2032 3V lithium battery.)
General Specification
Input Power	24±20% VDC (19.2~28.8VDC)
Power Consumption	1.25A@24VDC
CE	Complies with EN50081-2 and EN50082-2 standards
FCC	Complies with FCC Class A
Voltage resistance	500VAC (1 min.)
Isolation resistance	Exceed 50MW at 500VDC
Vibration endurance	10 to 25 Hz (X,Y,Z direction 2G 30minutes)
Protection structure	IP65 front panel (O ring seal)
Operating Temperature	0~45°C
Operation humidity	10-90% RH (non –condense)
Enclosure	Plastic
Dimensions WxHxD	286x212x50mm
Panel cutout dimension	259 x 201 mm
Weight	Approx. 1.6 kg
Operating System
Operating System	EB8000 V1.3.0 or Newer
