| Thông số | Giá trị |
|---|---|
| Model | KV-XL202 |
| Type | Serial communication unit |
| Communication standard | RS-232C |
| Connection interface | European terminal block with 7 poles (detachable) × 2 ports |
| Electrical termination (terminator) | – |
| Transmission rate | 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400 bps |
| Transmission method | Full duplex |
| Data format | Start bit: 1 bitData bit: 7 bits, 8 bitsStop bit: 1 bit, 2 bits |
| Error detection | Parity: Even, odd, none |
| RS/CS flow control | ON or OFF |
| Transmission distance | 15 m49.2′ |
| Number of transmission units | 1 |
| Refresh | Automatic refresh, direct refresh, inter-unit synchronization refresh |
| Serial communication functions | Non-procedure, PROTOCOL STUDIO, Modbus slave, etc. |
| Serial communication function execution methods | Ladder program, unit program (flow) |
| Unit program capacity | 3 MB (Max. number of blocks: Approx. 20000) |
| Max. number of flows | 256 |
| Number of simultaneous activities (Flow) | Unlimited |
| Internal data Memory (Flow) | 524288 words |
| Transmission method (PROTOCOL STUDIO) | Cyclic communication: Tx + Rx, Tx only, Rx onlyEvent communication: Tx + Rx, Tx only, Rx only, Tx + Continuous Rx, Break Tx |
| Max. number of connected devices (PROTOCOL STUDIO) | 2 |
| Max. number of communication commands (PROTOCOL STUDIO) | 48/96*1 |
| Maximum number of total frames (PROTOCOL STUDIO) | Rx: 48/96*1× 16;Tx: 48/96*1× 1 |
| Max. number of compared received frames (PROTOCOL STUDIO) | 16 per command |
| Maximum number of block elements (PROTOCOL STUDIO) | 96 per frame |
| Transmission data length (PROTOCOL STUDIO) | 1 to 2048 bytes per frame |
| Communication patterns (PLC link) | Write, read, transfer |
| Number of link settings (PLC link) | 512 settings max.*2 |
| Link data size (PLC link) | 1440 words max. per setting (bit: 720 words, word: 720 words)737280 words max. (total) (1440 words × 512 settings) |
| Data unit (PLC link) | 1 word |
| Number of connected models (PLC link) | 2 models max. (1 model × 2 ports) |
| Number of connected units (PLC link) | 2 max. (1 unit × 2 ports) |
| Trigger types (PLC link) | Cyclic/event (64 settings max. for event*2) |
| Update interval (PLC link) | 10 to 65535 ms |
| Internal current consumption | 140 mA or less |
| Weight | Approx. 200 g |
Module truyền thông Keyence KV-XL202 (RS-232C×2)
SKU: KV-XL202
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
