Name: Module truyền động Keyence KV-MC20V 2 vị trí
Brand: Keyence
SKU: KV-MC20V
Availability: InStock

Thông số	Giá trị
Model	KV-MC20V
Type	Positioning/Motion unit
Number of control axes	2 axes
Built-in device	Relay: 896 points (56 ch), Data memory: 54 words (high speed)/402 words (simple)
Output format	Differential line driver output (switchable among 1-pulse method, 2-pulse method, and A/B-phase method)
Connectable CPU units	KV-5500/5000/3000
Max. output pulse	4 MHz
Control mode	Position control
Control period	1.0 ms
External interface	Input: Photocoupler input, Output: Open collector output (30 VDC 50 mA)
Input time constant	Each input is set in 11 stages for each block
Axis control function execution method	Ladder program, motion flow
Motion flow – Program capacity	768 KB
Motion flow – Max. number of blocks	A total of 256 blocks in all flows
Motion flow – Max. number of flows	32
Motion flow – Number of simultaneous activities	Number of connectable axes × 2
Position unit	mm, deg (angle), PLS (pulse count), decimal point position from 0 to 9 digits, unit conversion function available
Cumulative address	-2,147,483,648 to +2,147,483,647 instruction units
Positioning mode	Absolute value/relative value
Position setting range	-2,147,483,648 to +2,147,483,647 instruction units
Interpolation	Straight-line interpolation (up to 16 axes), arc interpolation, helical interpolation
Acceleration/deceleration curve	Straight-line, SIN, Bezier
Start-up time	Independent: 500 to 600 µs, Interpolation (straight-line 2 axes): 600 to 700 µs, Interpolation (arc 2 axes): 700 to 800 µs, Interpolation (helical 3 axes): 800 to 900 µs (only for KV-MC40V) (When the 1st axis is activated)
M-code	1 to 65,000, WITH/AFTER mode
Sensor positioning	External input – based switching control from speed to position
Number of points	800 points/axis
Synchronisation control – Input	Counter (KV-MX1 required), instruction coordinates, current coordinates (KV-ML16V only)
Fine control – Fine data work area	8 MB
Fine control – Built-in ROM capacity	512 KB
Fine control – Number of settings	Built-in ROM: 100, SD memory card: 1000
Fine control – Data capacity of one setting	Built-in ROM: 512 KB, SD memory card: 8 MB (KV-MX1 required)
Origin return method	Origin sensor edge/midpoint, push origin return, Dog type (“With Z phase” or “Without Z phase” can be selected), data set type, no limit switch
Speed control – Speed instruction range	–
Torque control	Torque instruction range
JOG/Inching	Inching (The number of pulses can be specified), JOG (high speed/low speed)
Teaching	Current coordinate teaching and teaching from the counter current value are supported
Memory data	Point parameters 800 points (each axis), synchronisation parameters (each axis), fine setting (built-in ROM: 512 KB, expandable with SD card), cam data motion flow setting, etc. can be read and written during RUN (with some restrictions)
High-speed counter	When KV-MX1 is connected: INC 4 ch/ABS Grey, residual Grey, binary 2 ch (switched, based on settings), Max. 6.4 MHz (2-phase, 4 multiplication)
5-V power output	5 V ±5%, Max. 100 mA (total value)
Output display	Error status/Pulse output status
Self-diagnosis function	Diagnosis can be made through hardware error, various parameter errors, error number, and error messages
Parameter setting	Parameters can be set from KV-HPD1, “KV STUDIO,” and ladder programs
Data backup	Coordinates and error/warning history backup, parameter settings backup via flash ROM, 100,000 times switching
Internal current consumption	Main unit: 120 mA or less, external I/O: 80 mA or less
Weight	Approx. 170 g
