Name: Module nhiệt độ Keyence KV-NC4TP (4 ngõ vào)
Brand: Keyence
SKU: KV-NC4TP
Availability: InStock

Module nhiệt độ Keyence KV-NC4TP (4 ngõ vào)

SKU: KV-NC4TP
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

4.500.000 ₫

SKU: KV-NC4TP Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-NC4TP
Number of Inputs	4*1
Input Type	Thermocouple, Platinum resistance thermometer
Input Range (Thermocouple)	K: -270.0 to 1372.0°C (-454 to 2501.6°F)J: -210.0 to 1200.0°C (-346 to 2192°F)T: -270.0 to 400.0°C (-454 to 752°F)E: -270.0 to 1000.0°C (-454 to 1832°F)N: -270.0 to 1300.0°C (-454 to 2372°F)R: -50.0 to 1768.0°C (-58 to 3214.4°F)S: -50.0 to 1768.0°C (-58 to 3214.4°F)B: 0.0 to 1820.0°C (32 to 3308°F)WRe5-26: 0.0 to 2315.0°C (32 to 4199°F)
Input Range (Platinum resistance thermometer)	Pt100: -200.0 to 850.0°C (-328 to 1562°F)JPt100: -200.0 to 600.0°C (-328 to 1112°F)
Overall Accuracy (Thermocouple, at 25°C ±5°C)	±(0.2% of F.S. +1°C)
Overall Accuracy (Thermocouple, at 0 to 55°C)	±(0.4% of F.S. +1°C)
Overall Accuracy (Platinum resistance thermometer, at 25°C ±5°C)	±0.2% of F.S.
Overall Accuracy (Platinum resistance thermometer, at 0 to 55°C)	±0.4% of F.S.
Allowable Wiring Resistance (Platinum resistance thermometer)	100 Ω max./wire (no variation allowed among three wires)
Conversion Speed	125 ms/channel
Isolation Method	Between input terminals and base unit: Photocoupler/semiconductor relay/transformer isolationBetween channels (When resistance thermometer is not used): Semiconductor relay isolationBetween channels (When resistance thermometer is used): No isolation
Special Functions	Channel skip, disconnection detection, averaging (time average, count average, moving average), special data offset, peak-/bottom-hold, alarm, abnormal input setting
Internal Current Consumption	40 mA or less
Weight	Approx. 110 g
