Name: Module Keyence KV-SIR32XT (32 in/ 32 out transistor)
Brand: Keyence
SKU: KV-SIR32XT
Availability: InStock

Thông số	Giá trị
Model	KV-SIR32XT
Type	High-speed I/O unit
External connection method	Connector (MIL specification)*1
Number of inputs	32 points
Input mode	24 VDC mode, 5 VDC mode2(with overvoltage protection function3)
Maximum input voltage	24 VDC mode: 28.8 VDC5 VDC mode: 6.0 VDC
Rated input voltage	24 VDC mode: 24 VDC, 5.1 mA5 VDC mode: 5 VDC, 8.8 mA
Minimum ON voltage	24 VDC mode: 19 V5 VDC mode: 3.5 V
Maximum OFF current	24 VDC mode: 1.5 mA
Maximum OFF voltage	5 VDC mode: 1.5 V
Common method	16 points/1 common (2 terminals)*4
Input time constant	1 μs/10 μs/20 μs/100 μs/500 μs/1 ms/5 ms/10 ms/50 ms
Input impedance	24 VDC mode: 4.4 kΩ5 VDC mode: 350 Ω
Number of outputs	32 points
Output mode	MOSFET (sink) (with overcurrent protection function)*5
Rated load	30 VDC, 0.2 A (1.6 A/1 common)
Leakage current at OFF	100 μA or less
Residual voltage at ON	0.5 VDC or less
Common method	16 points/1 common (2 terminals)*4
Operation time	OFF to ON: 1 μs or less: (Load: 5 mA to 200 mA)ON to OFF: 5 μs or less: (Load: 5 mA to 200 mA)
Internal current consumption	130 mA or less
Weight	Approx. 190 g
