Name: Module Keyence KV-NC32EXT (32 in/ 32 out transistor)
Brand: Keyence
SKU: KV-NC32EXT
Availability: InStock

Thông số	Giá trị
Model	KV-NC32EXT
Type	Expansion I/O unit
External Connection Method	Connector
Number of Inputs	32
Input Terminals	24 VDC mode
Maximum Input Voltage	26.4 VDC
Input Rated Voltage (24 VDC mode)	3.6 mA
Input Rated Voltage (5 VDC mode)	―
Minimum ON Voltage (24 VDC mode)	19 V
Minimum ON Voltage (5 VDC mode)	―
Maximum OFF Current (24 VDC mode)	1.5 mA
Maximum OFF Voltage (24 VDC mode)	―
Common Method (Input)	32 points/1 common (2 terminals)*1
Input Time Constant (OFF to ON, Typ.)	25 μs : 10 μs300 μs : 240 μs1 ms : 1 ms10 ms : 10 ms
Input Time Constant (OFF to ON, Max.)	25 μs : 50 μs300 μs : 290 μs1 ms : 1.2 ms10 ms : 11 ms
Input Time Constant (ON to OFF, Typ.)	25 μs : 50 μs300 μs : 280 μs1 ms : 1 ms10 ms : 10 ms
Input Time Constant (ON to OFF, Max.)	25 μs : 150 μs300 μs : 390 μs1 ms : 1.2 ms10 ms : 11 ms
Input Impedance	6.3 kΩ
Number of Outputs	32
External Connection Method (Output)	MOSFET (N-ch) (with overcurrent protection function)*2
External Connection Method (Output)	Connector
Rated Load	30 VDC, 0.2 A*3
Leakage Current (at OFF)	100 μA or less
Residual Voltage (at ON)	0.6 VDC or less
Common Method (Output)	32 points/1 common (2 terminals)*1
Response Time (OFF to ON)	100 μs or less (with a load of 1 mA or more)
Response Time (ON to OFF)	200 μs or less (with a load of 1 mA or more)
Internal Current Consumption	60 mA or less
Weight	Approx. 150 g
