Module Keyence KV-NC20L RS-232C/422A/485

SKU: KV-NC20L
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

SKU: KV-NC20L Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-NC20L
Electrical termination (Terminator)	Set with the switch on the front panel of the main unit
Baud rate	1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
Transmission method	Port1: Full duplex, Port2: Full duplex, Half duplex
Start bit	1 bit
Data bits	7 bits, 8 bits
Stop bits	1 bit, 2 bits
Error detection	Parity (Even, Odd, None)
RS/CS flow control	Port1: Enabled, disabled
Communication standard	Port 1: RS-232C, Port 2: RS-232C, RS-422A/RS-485 (4-wire), RS-485 (2-wire)
Connection	Port 1: D-sub 9-pin, Port 2: European terminal block
Transmission distance	Port1: 15 m (49.2′), Port2: 15 m (49.2′), Extendable up to 1200 m (3937.0′)
Number of transmission units	Port1: 1, Port2: 1, 32
Indication	SD (orange), RD (orange)
Weight	Approx. 110 g
