Module Keyence KV-NC16ETP (16 ngõ ra transistor)

Name: Module Keyence KV-NC16ETP (16 ngõ ra transistor)
Brand: Keyence
SKU: KV-NC16ETP
Availability: InStock

SKU: KV-NC16ETP
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

3.400.000 ₫

SKU: KV-NC16ETP Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-NC16ETP
Type	Expansion output unit
External Connection Method	MOSFET (With overcurrent protection function)12
External Connection Method	Connector
Rated Load	30 VDC, 0.2 A*3
Leakage Current (at OFF)	100 μA or less
Residual Voltage (at ON)	0.6 VDC or less
ON Resistance	−
Common Method	16 points/1 common (2 terminals)45
Response Time (OFF to ON)	100 μs or less (with a load of 1 mA or more)
Response Time (ON to OFF)	200 μs or less (with a load of 1 mA or more)
Relay Life	−
Relay Replacement	−
Internal Current Consumption	30 mA or less
Weight	Approx. 100 g
