Module Keyence KV-N1AW

Thông số	Giá trị
Model	KV-N1AW
Power voltage	Supplied from the base unit
Operating ambient temperature	0 to +55°C (no freezing)
Operating ambient humidity	5 to 90% RH (no condensation)
Noise immunity	1500 V peak-to-peak or more, pulse width 1 µs, 50 ns (by noise simulator), IEC standard compliant (IEC61000-4-2/3/4/6)
Insulation resistance	50 MΩ or more (500 VDC megger used to perform measurements between power terminal and input terminals, and between all external terminals and case)
Storage temperature	-25 to +75°C
Storage relative humidity	35 to 85% RH (no condensation)
Intermittent vibration (Frequency: 5 to 9 Hz)	Amplitude: 3.5 mm
Intermittent vibration (Frequency: 9 to 150 Hz)	Acceleration: 9.8 m/s²
Continuous vibration (Frequency: 5 to 9 Hz)	Amplitude: 1.75 mm
Continuous vibration (Frequency: 9 to 150 Hz)	Acceleration: 4.9 m/s²
Shock resistance	Acceleration: 150 m/s², application time: 11 ms, two times in each of the X, Y, and Z directions
Altitude	2000 m or less
Pollution degree	2
Number of times the product can be connected and disconnected	200
Memory save method	Flash ROM can be rewritten 10,000 times
Weight	Approx. 30 g

Thông tin bổ sung

Thương hiệu	Keyence
