Name: Module Keyence KV-H40S
Brand: Keyence
SKU: KV-H40S
Availability: InStock

Thông số	Giá trị
Attribute	Specification
Model	KV-H40S
Type	Positioning module
Control Mode	Positioning (PTP: point-to-point), control (independent, interpolation), speed control (independent), speed-to-position control (independent)
Controlled Axes	4 axes/independent block 4 axes, Interpolation 2 to 4 axes (linear)
Start Time	Independent operation: 1.5 ms, linear interpolation: 1.8 ms
Position Guide	Incremental ±99,999,999 (pulses, mm, degrees), Absolute value management range (-2,147,483,648 to 2,147,483,647)
Acceleration/Deceleration	1 – 65,000 (p/s/ms, mm/s/ms, deg/s/ms), 65,000 set as instantaneous acceleration/deceleration, control time 2 ms
Positioning Points	200 points/axis
Acceleration/Deceleration Mode	Linear, Sine curve (S-curve)
Speed Guide	1 to 1,000,000 p/s
Pulse Output Station	Output different transmission controller (1 pulse, 2 pulse switching)
Memory Backup	Super-fast memory
Other Functions	Test run function, sensor stop interrupt function, continuous operation, approach control method
Current Consumption	Up to 130 mA, for KZ-HP1/KV-HPD1 connectors: Input/Output up to 220 mA: up to 180 mA
Weight	Approx. 200g

Thông tin bổ sung

Thương hiệu	Keyence

Module Keyence KV-H40S
