Module Keyence KV-H20G

Thông số	Giá trị
Attribute	Specification
Model	KV-H20G
Type	Sync/Cam motion block
Control Mode	Positioning (PTP: point-to-point), control (independent, linear/arc interpolation), speed control (independent), speed-to-position control (independent), synchronization control
Controlled Axes	2 axes/block, 2 independent axes, 2 interpolated axes (linear, arc)
Start Time	Independent operation: 1.5 ms, Linear interpolation: 1.8 ms, Arc linear interpolation: 2.1 ms
Position Guide	±99,999,999 (pulses, mm, degrees), Incremental, Absolute value management range (-2,147,483,648 to 2,147,483,647)
Acceleration/Deceleration	1 – 65,000 (p/s/ms, mm/s/ms, deg/s/ms), 65,000 set as instantaneous acceleration/deceleration, control time 2 ms
Positioning Points	400 points/axis
Acceleration/Deceleration Mode	Linear, Sine curve (S-curve)
Speed Guide	1 to 1,000,000 p/s
High-Speed Counter	With 24-bit 2-phase 2-channel (INC)/up to 12-bit (ABS), Gray code, Gray overflow, Binary conversion, Comparison 2 points/cam switch output 8 points, Max 500 kp/s
Pulse Output Station	Output different transmission controller (1 pulse, 2 pulse switching)
Memory Backup	Super-fast memory
Other Functions	Test run function, sensor stop interrupt function, continuous operation, approach control method
Current Consumption	Below 130 mA, when connected to KZ-HP1/KV-HPD1: Input/Output below 200 mA: below 150 mA
Weight	Approx. 200g

Thông tin bổ sung

Thương hiệu	Keyence
