| Thông số | Giá trị |
|---|---|
| Model | KV-E4XT |
| Number of Inputs | 4 |
| Minimum ON Voltage | 19V |
| Maximum OFF Current | 2mA |
| Input Time Constant | 10 ms ± 20%, 10 µs ± 20% (switchable between 2 levels by using special auxiliary relays 2609 to 2612 for both rising (OFF to ON) and falling (ON to OFF) edges) |
| Number of Outputs | 4 |
| Output Type | Transistor (NPN)*1 |
| Rated Load Voltage | 30 VDC |
| Rated Output Current | 0.5 A/output |
| Leakage Current (at OFF) | 100 µA or less |
| Residual Voltage (at ON) | 0.8 V or less |
| Startup Operation Time (OFF → ON) | 50 µs or less |
| Startup Operation Time (ON → OFF) | 250 µs or less |
| ON Resistance | ― |
| Relay Life Span | ― |
| Relay Replacement | ― |
| Weight | Approx 100g |
| Input Maximum Rating (24V Mode) | 26.4 VDC |
| Input Voltage (24V Mode) | 24 VDC, 5.3 mA |
| Input Impedance (24V Mode) | 4.3 kΩ |
| Common Input | 4/common |
| Common Output | 4/common |
| External Connection Method | Terminal block |
Module Keyence KV-E4XT (4 in/4 out transistor)
SKU: KV-E4XT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
1.600.000 ₫
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
