Name: Module Keyence KV-DN20
Brand: Keyence
SKU: KV-DN20
Availability: InStock

Thông số	Giá trị
Model	KV-DN20
Type	DeviceNet™ unit
Communication Protocol	Compliant with DeviceNet™
Transmission Rate	500 kbps, 250 kbps, 125 kbps
Transmission Media	5 dedicated cables (2 signal, 2 power, 1 shield)
Connection Topology	Multidrop method
Max. Cable Length	Thick cable: 500m (125 kbps), 250m (250 kbps), 100m (500 kbps); Thin cable: 100m (all speeds)
Max. Connected Nodes	64 (including master, slave, configurator)
Master Mode – Connected Pieces per Network	Max. 64
Master Mode – Communication Type	I/O communication (Poll/Bit-Strobe/COS/Cyclic), Explicit message communication
Master Mode – Device Assignment	Auto configuration, manual assignment
Slave Mode – Connected Pieces per Network	Max. 64
Slave Mode – Communication Type	I/O communication (Poll), Explicit message communication
Internal Current Consumption	24 VDC, 45 mA (internal), 24 VDC, 25 mA (communication circuit)
Weight	Approx. 150 g

Thông tin bổ sung

Thương hiệu	Keyence
