Module Keyence KV-DA40

SKU: KV-DA40
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

SKU: KV-DA40 Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-DA40
Type	Analog-Digital Conversion Module
Analog Input/Output Points	4 points
Analog Input/Output Range (Resolution)	Voltage: -10 to +10 V (2.5 mV 1/8,000), 0 to 10 V (2.5 mV 1/4,000), 0 to 5 V (1.25 mV 1/4,000), 1 to 5 V (1.25 mV 1/3,200); Current: 0 to 20 mA (5 µA 1/4,000), 4 to 20 mA (5 µA 1/3,200)
Input Impedance	–
Conversion Speed	80 µs/channel
Conversion Accuracy (25 °C ±5 °C)	Voltage: ±0.2 % of F.S., Current: ±0.2 % of F.S.
Conversion Accuracy (0 to 50 °C)	Voltage: ±0.4 % of F.S., Current: ±0.4 % of F.S.
Isolation Mode	Between the module and CPU: opto-coupler isolated, channels are not isolated
Minimum Load Impedance	Voltage: 1 kΩ
Maximum Load Impedance	Current: 400 Ω
Current Consumption	Up to 230 mA
Weight	Approx. 150 g
