Module Keyence KV-C64XC (64 ngõ vào)

Name: Module Keyence KV-C64XC (64 ngõ vào)
Brand: Keyence
SKU: KV-C64XC
Availability: InStock

SKU: KV-C64XC
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

3.100.000 ₫

SKU: KV-C64XC Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-C64XC
Type	Input Unit
External Connection Method	Connector (MIL standard)*1
Number of Inputs	64 points
Input Mode	24 VDC mode*2
Maximum Input Voltage	26.4 VDC
Rated Input Voltage	24 VDC, 4.1 mA
Minimum ON Voltage	19 V
Maximum OFF Current	1.5 mA
Maximum OFF Voltage	–
Common Method	32 points/1 common (2 terminals) × 2*3
Input Time Constant (25 µs Setting)	OFF to ON: Typ. 25 µs/Max. 65 µsON to OFF: Typ. 75 µs/Max. 120 µs
Input Time Constant (300 µs Setting)*4	OFF to ON: Typ. 275 µs/Max. 365 µsON to OFF: Typ. 275 µs/Max. 420 µs
Input Time Constant (1 ms Setting)	OFF to ON: Typ. 1 ms/Max. 1.2 msON to OFF: Typ. 1 ms/Max. 1.2 ms
Input Time Constant (10 ms Setting)	OFF to ON: Typ. 10 ms/Max. 12 msON to OFF: Typ. 10 ms/Max. 12 ms
Input Impedance	5.6 kΩ
Internal Current Consumption	25 mA or less
Weight	Approx. 140 g
