Name: Module Keyence KV-C64TCP (64 ngõ ra transistor)
Brand: Keyence
SKU: KV-C64TCP
Availability: InStock

Module Keyence KV-C64TCP (64 ngõ ra transistor)

SKU: KV-C64TCP
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

3.100.000 ₫

SKU: KV-C64TCP Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-C64TCP
Type	Output unit
External Connection Method	Connector (MIL standard)*1
Number of Outputs	64 points
Output Mode	Transistor (source)
Rated Load	30 VDC, 0.2 A
Leakage Current at OFF	100 μA or less
Residual Voltage at ON	0.5 V or less
ON Resistance	–
Common Method	64 points/1 common (4 terminals)*2
Operation Time	OFF to ON: 50 μs or lessON to OFF: 200 μs or less
Internal Current Consumption	100 mA or less
Weight	Approx. 140 g
