Name: Module Keyence KV-C16XTD (16 in/ 16 out transistor)
Brand: Keyence
SKU: KV-C16XTD
Availability: InStock

Module Keyence KV-C16XTD (16 in/ 16 out transistor)

SKU: KV-C16XTD
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

4.500.000 ₫

SKU: KV-C16XTD Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-C16XTD
Type	I/O unit
External Connection Method	Connector (MIL standard)*1
Number of Inputs	16 points
Input Mode	24 VDC mode, 5 VDC mode
Maximum Input Voltage	26.4 VDC
Rated Input Voltage (24 VDC mode)	24 VDC, 5.3 mA
Rated Input Voltage (5 VDC mode)	5 VDC, 1 mA
Minimum ON Voltage (24 VDC mode)	19 V
Minimum ON Voltage (5 VDC mode)	3.5 V
Maximum OFF Current (24 VDC mode)	1.5 mA
Maximum OFF Voltage (5 VDC mode)	1.5 V
Common Method (Input)	16 points/1 common (1 terminal)
Input Time Constant	25 μs/300 μs*2/1 ms/10 ms
Input Impedance	4.3 kΩ
Number of Outputs	16 points
Output Mode	MOSFET (sink) (with overcurrent protection function)
Rated Load	30 VDC, 0.2 A
Leakage Current at OFF	100 μA or less
Residual Voltage at ON	0.5 VDC or less
Common Method (Output)	16 points/1 common (1 terminal)
Operation Time (OFF to ON)	100 μs or less
Operation Time (ON to OFF)	300 μs or less
Internal Current Consumption	40 mA or less
Weight	Approx. 110 g
