Module Keyence KV-B8XTD (8 in/ 8 out transistor)

SKU: KV-B8XTD
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

SKU: KV-B8XTD Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-B8XTD
Type	I/O unit
External Connection Method	Removable terminal block
Number of Inputs	8 points
Input Mode	24 VDC mode, 5 VDC mode
Maximum Input Voltage	26.4 VDC
Rated Input Voltage (24 VDC mode)	24 VDC, 5.3 mA
Rated Input Voltage (5 VDC mode)	5 VDC, 1 mA
Minimum ON Voltage (24 VDC mode)	19 V
Minimum ON Voltage (5 VDC mode)	3.5 V
Maximum OFF Current (24 VDC mode)	1.5 mA
Maximum OFF Voltage (5 VDC mode)	1.5 V
Common Method (Input)	8 points/1 common (1 terminal)
Input Time Constant	25 μs/300 μs*1/1 ms/10 ms
Input Impedance	4.3 kΩ
Number of Outputs	8 points
Output Mode	MOSFET (sink) (with overcurrent protection function)
Rated Load	30 VDC, 0.3 A
Leakage Current at OFF	100 μA or less
Residual Voltage at ON	0.5 VDC or less
Common Method (Output)	8 points/1 common (1 terminal)
Operation Time (OFF to ON)	100 μs or less
Operation Time (ON to OFF)	300 μs or less
Internal Current Consumption	30 mA or less
Weight	Approx. 130 g
