Module Keyence KV-B16TCP (16 ngõ ra transistor)

Name: Module Keyence KV-B16TCP (16 ngõ ra transistor)
Brand: Keyence
SKU: KV-B16TCP
Availability: InStock

SKU: KV-B16TCP
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

4.500.000 ₫

SKU: KV-B16TCP Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-B16TCP
Type	Output unit
External Connection Method	Removable terminal block
Number of Outputs	16 points
Output Mode	Transistor (source)
Rated Load	30 VDC, 0.2 A
Leakage Current at OFF	100 μA or less
Residual Voltage at ON	0.5 V or less
ON Resistance	–
Common Method	16 points/1 common (2 terminals)*1
Operation Time	OFF to ON: 10 μs or lessON to OFF: 200 μs or less
Internal Current Consumption	30 mA or less
Weight	Approx. 130 g
