Module Keyence KV-AD40V

Name: Module Keyence KV-AD40V
Brand: Keyence
SKU: KV-AD40V
Availability: InStock

SKU: KV-AD40V
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

5.200.000 ₫

SKU: KV-AD40V Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-AD40V
Type	A/D Conversion Unit
Analog Input Points	4 points (differential input)
Analog Input Range (Voltage)	-10 to +10 V (0.5 mV 1/40,000)-5 to +5 V (0.25 mV 1/40,000)0 to 10 V (0.5 mV 1/20,000)0 to 5 V (0.25 mV 1/20,000)1 to 5 V (0.25 mV 1/16,000)
Analog Input Range (Current)	0 to 20 mA (1 µA 1/20,000)4 to 20 mA (1 µA 1/16,000)
Input Impedance (Voltage)	5 MΩ
Input Impedance (Current)	250 Ω
Conversion Speed	25 µs/ch*1
Conversion Accuracy (25 °C ±5 °C)	Voltage: ±0.1 % of F.S.*2Current: ±0.1 % of F.S.
Conversion Accuracy (0 to 50 °C)	Voltage: ±0.2 % of F.S.*3Current: ±0.2 % of F.S.
Insulation Mode	Between unit and CPU: Photocoupler insulationBetween channels: Non-isolated
Absolute Maximum Input (Voltage)	±15 V
Absolute Maximum Input (Current)	30 mA
Internal Current Consumption	140 mA or less
Weight	Approx. 150 g
