Module Keyence KV-AD40

Name: Module Keyence KV-AD40
Brand: Keyence
SKU: KV-AD40
Availability: InStock

SKU: KV-AD40
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

4.600.000 ₫

SKU: KV-AD40 Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-AD40
Type	A/D Conversion Block
Analog I/O Points	4 points (Differential inputs)
Analog Input/Output Range (Voltage)	-10 to +10 V (2.5 mV / 1/8,000), 0 to 10 V (2.5 mV / 1/4,000), 0 to 5 V (1.25 mV / 1/4,000), 1 to 5 V (1.25 mV / 1/3,200)
Analog Input/Output Range (Current)	0 to 20 mA (5 µA / 1/4,000), 4 to 20 mA (5 µA / 1/3,200)
Input Impedance (Voltage)	1 MΩ
Input Impedance (Current)	250 Ω
Conversion Speed	80 µs/ch
Conversion Accuracy (25°C ±5°C)	Voltage: ±0.2% of F.S., Current: ±0.2% of F.S.
Conversion Accuracy (0 to 50°C)	Voltage: ±0.2% of F.S., Current: ±0.2% of F.S.
Isolation Mode	Between block and CPU: Optical isolation, channels not isolated
Maximum Absolute Input (Voltage)	±15 V
Maximum Absolute Input (Current)	30 mA
Current Consumption	110 mA or less
Weight	Approximately 150 g
