| Thông số | Giá trị |
|---|---|
| Model | KL-8BXR |
| Disconnection Error Output Load | 30 VDC, 0.1 A or less, residual voltage: 1 V or less |
| Vibration Resistance | 10 to 55 Hz, 1.5 mm or less double amplitude for 2 hours in each of the X, Y, and Z directions; 1 G when attached to a DIN rail |
| Insulation System | – |
| Power Voltage | 10.8 to 26.4 VDC (for the connector type I/O unit, supplied by the dedicated cable) |
| Operating Ambient Temperature | 0 to 60°C |
| Operating Ambient Humidity | 35 to 85%RH (no condensation) |
| Operating Environment | No corrosive gas present |
| Noise Immunity | Power supply common: 1,500 V, power supply normal: 500 V, pulse width: 1 ms, 50 ns (via a noise simulator) |
| Withstand Voltage | 500 VAC for 1 minute (between the power supply terminal and the I/O terminals; excluding the ERR output terminal) |
| Insulation Resistance | – |
| Input Maximum Rating | – |
| Input Voltage | – |
| Minimum ON Voltage | – |
| Maximum OFF Current | – |
| Maximum OFF Voltage | – |
| Input Impedance | – |
| Number of Inputs/Outputs | 8 DC inputs + 8-terminal terminal block relay output |
| Internal Current Consumption | 250mA or less |
| Weight | Approx. 190g |
| Output Specifications | – |
| Output Type | – |
| Relay Output Rated Voltage | AC250V/DC30V |
| Rated Output Current | 2 A/output (inductive load), 4 A/output (resistive load), 4 A/all commons |
| Common Ground | Written on the terminal wiring diagram of each unit |
| ON Resistance | 50 mΩ or less |
| ON Delay Time | 10ms or less |
| OFF Delay Time | 10ms or less |
| Insulation Resistance | 20 MΩ or more (tested with a 500 VDC megger, between the power supply terminal and the I/O terminals; excluding the ERR output terminal) |
| Insulation System | Relay isolation |
Module Keyence KL-8BXR (8 in/ 8 out relay)
SKU: KL-8BXR
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
