| Thông số | Giá trị |
|---|---|
| Model | KL-8BLT |
| Disconnection Error Output Load | 30 VDC, 0.1 A or less, residual voltage: 1 V or less |
| Vibration Resistance | 10 to 55 Hz, 1.5 mm or less double amplitude for 2 hours in each of the X, Y, and Z directions; 1 G when attached to a DIN rail |
| Insulation System | – |
| Power Voltage | 10.8 to 26.4 VDC (for the connector type I/O unit, supplied by the dedicated cable) |
| Operating Ambient Temperature | 0 to 60°C |
| Operating Ambient Humidity | 35 to 85%RH (no condensation) |
| Operating Environment | No corrosive gas present |
| Noise Immunity | Power supply common: 1,500 V, power supply normal: 500 V, pulse width: 1 ms, 50 ns (via a noise simulator) |
| Withstand Voltage | 500 VAC for 1 minute (between the power supply terminal and the I/O terminals; excluding the ERR output terminal) |
| Insulation Resistance | – |
| Input Maximum Rating | – |
| Input Voltage | – |
| Minimum ON Voltage | – |
| Maximum OFF Current | – |
| Maximum OFF Voltage | – |
| Input Impedance | – |
| Number of Inputs/Outputs | 8-terminal terminal block transistor output |
| Internal Current Consumption | 80mA or less |
| Weight | Approx. 130g |
| Output Specifications | – |
| Output Type | NPN open collector |
| Residual Voltage (when output is ON) | 0.8V or less |
| Leakage Current (when output is OFF) | 100 µA or less |
| Transistor Output Rated Load Voltage | 30 V DC and 5 to 26.4 V DC (power source supplied across VC and C) |
| Rated Output Current | 0.5 A/output (when 24 V or more is applied across VC and C), 0.15 A/output (when 12 V or more is applied across VC and C), 0.05 A/output (when 5 V or more is applied across VC and C) |
| Common Ground | Written on the terminal wiring diagram of each unit |
| ON Delay Time | 25 µs or less |
| OFF Delay Time | 200 µs or less |
| Insulation Resistance | 20 MΩ or more (tested with a 500 VDC megger, between the power supply terminal and the I/O terminals; excluding the ERR output terminal) |
| Insulation System | Photocoupler isolation |
| Relay Output Specifications | – |
Module Keyence KL-8BLT (8 ngõ ra transistor)
SKU: KL-8BLT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Báo giá
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
