| Thông số | Giá trị |
|---|---|
| Model | KL-32CT |
| Disconnection Error Output Load | 30 VDC, 0.1 A or less, residual voltage: 1 V or less |
| Vibration Resistance | 10 to 55 Hz, 1.5 mm or less double amplitude for 2 hours in each of the X, Y, and Z directions; 1 G when attached to a DIN rail |
| Power Voltage | 10.8 to 26.4 VDC (for the connector type I/O unit, this is supplied by the dedicated cable) |
| Operating Ambient Temperature | 0 to 60°C |
| Operating Ambient Humidity | 35 to 85%RH (no condensation) |
| Operating Environment | No corrosive gas present |
| Noise Immunity | Power supply common: 1,500 V, power supply normal: 500 V, pulse width: 1 ms, 50 ns (via noise simulator) |
| Withstand Voltage | 500 VAC for 1 minute (between power supply terminal and I/O terminals; excluding ERR output terminal) |
| Insulation Resistance | 20 MΩ or more (tested with a 500 VDC megger, between power supply terminal and I/O terminals; excluding ERR output terminal) |
| Input Maximum Rating | Not specified |
| Input Voltage | Not specified |
| Minimum ON Voltage | Not specified |
| Maximum OFF Current | Not specified |
| Maximum OFF Voltage | Not specified |
| Input Impedance | Not specified |
| Number of Inputs/Outputs | 32-connector transistor output |
| Internal Current Consumption | 140mA or less |
| Weight | Approx. 100g |
| Output Type | NPN open collector |
| Residual Voltage (ON) | 0.8V or less |
| Leakage Current (OFF) | 100 µA or less |
| Rated Load Voltage (Transistor Output) | 30 V DC and 5 to 26.4 V DC (power supplied across VC and C) |
| Rated Output Current (Transistor Output) | 0.5 A/output (when 24 V or more is applied across VC and C); 0.15 A/output (when 12 V or more is applied across VC and C); 0.05 A/output (when 5 V or more is applied across VC and C) |
| Common Ground (Transistor Output) | Refer to terminal wiring diagram |
| ON Delay Time (Transistor Output) | 25 µs or less |
| OFF Delay Time (Transistor Output) | 200 µs or less |
| Insulation Resistance (Transistor Output) | 20 MΩ or more (tested with a 500 VDC megger, between the power supply terminal and the I/O terminals; excluding ERR output terminal) |
| Insulation System (Transistor Output) | Photocoupler isolation |
Module Keyence KL-32CT
SKU: KL-32CT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Báo giá
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
