Name: Module EtherNet/IP Keyence KV-NC1EP
Brand: Keyence
SKU: KV-NC1EP
Availability: InStock

Thông số	Giá trị
Model	KV-NC1EP
Number of connections	64*1
RP I (communication cycle)	0.5 to 10000 ms (0.5 ms increments). Setting is possible for each connection. (Data is updated on the line at specified cycles, independent of the number of nodes.)
Transmission trigger: Output to the adapter	Cyclic
Transmission trigger: Input from the adapter	Cyclic/Change Of State*2
Tolerable communication bandwidth for cyclic communication (@504 bytes)	6000 (pps)*3
Tolerable communication bandwidth for cyclic communication (@1444 bytes)	3000 (pps)*3
Maximum number of refresh words	8000 words
Maximum data size per connection	504 bytes or 1444 bytes*4
Multicast filter function	Provided (IGMP client function)*5
Class 3 (connection type): Server	No. of connections: 64*6
UCMM (non-connection type): Client	No. of simultaneous messages: 32
UCMM (non-connection type): Server	No. of simultaneous messages: 96
EtherNet/IP™ conformance test	Conforming to CT10
PC applications	No. of sockets TCP: 8, UDP: 0, Port No.: 8500 (can be set within the range between 1 and 65535)*7
Host link communication	No. of sockets TCP: Total: 15, UDP: 1, Port No.: 8501 (can be set within the range between 1 and 65535)89
MC protocol communication	No. of sockets TCP: Total: 15, UDP: 1, Port No.: 5000 (can be set within the range between 1 and 65535)108*9
VT3 connection	No. of sockets TCP: 0, UDP: 1, Port No.: 8502 (can be set within the range between 1 and 65535)
FTP server	No. of sockets TCP: 4, Port No.: 20, 21
Clock data automatic adjustment	No. of sockets UDP: 1, Port No.: 123
DNS	No. of sockets UDP: 1, Port No.: 53
FTP client	No. of sockets TCP: 2, Port No.: 20, 21 (can be set within the range between 1 and 65535)
Easy PLC link	No. of sockets UDP: 1, Port No.: 5001 (can be set within the range between 1 and 65535)
EtherNet/IP™ cyclic communication function	No. of sockets TCP: Total: 320, UDP: 1, Port No.: 2222
EtherNet/IP™ message communication function	No. of sockets TCP: Total: 320, UDP: 1, Port No.: 44818
Internal current consumption	90 mA or less
Weight	Approx. 110 g

Thông tin bổ sung

Thương hiệu	Keyence

Module EtherNet/IP Keyence KV-NC1EP
