Module bộ đếm Keyence KV-SSC02

Thông số	Giá trị
Model	KV-SSC02
Type	High-speed counter unit
Input frequency	Single phase 4 MHz (16 MHz during 2-phase, 4-multiplication)
Counting range	32 bits
Number of channels	2 ch
Input selection	External terminal (CH0, CH1), internal clock (0.05 μs, 1 μs, 10 μs, 100 μs), other CH coincidence output, communication: EnDat2.2/22, BiSS (C-mode), YASKAWA serial
Input mode	1-pulse with/without direction, 2-pulse addition/subtraction operation, 2-phase 1-multiplication/2-multiplication/4-multiplication
Counting operation mode	• Up-down counting mode• Enable counting mode• Preset counting mode• Set timer counting mode• Enable accumulative counting mode
Counting mode	Linear, ring
Frequency, revolution counter operation mode	• Frequency counting mode• Revolution counter B mode (1-revolution time measurement)• Revolution counter A mode (pulse interval measurement)
Count input	A-phase/B-phase/Z-phase (preset), 3 points for each channel, 6 points in total5/12/24 VDC input possible, line driver input possible, photocoupler insulation
Control input	Enable (also used for input capture) input, 1 point for each channel, 2 points in total12 to 24 VDC input possible, photocoupler insulationInput capture input, 2 points for each (4 points in total)12 to 24 VDC input possible, photocoupler insulation
Comparator coincidence output	2 points for each channel, 4 points in total, photocoupler insulationRated load: 30 VDC, 0.2 A or less
Input capture function	By external input (max. 4 points)
Buffering function	Buffering period: 1 μs or more
Input filter function	Input time constant switching (6 types of counting/9 types of control)
Preset function	Possible to select from preset (Z-phase) input and internal relay-based rising edge/falling edge/level (only when an external input is used)
Supported encoder	Absolute encoders that support EnDat2.2/22, BiSS (C-mode), and YASKAWA serial
Communication cycle	EnDat2.2/22: 50 μs, BiSS (C-mode): 50 μs, YASKAWA serial: 62.5 μs
Input (Serial Encoder)	Equivalent to a differential line receiver that meets the EIA RS485 standard
Output (Serial Encoder)	Equivalent to a differential line driver that meets the EIA RS485 standard
Encoder 5 V power	5 VDC (±5%), 300 mA or less
Others	Unit interrupt, inter-unit synchronization
Internal current consumption	190 mA or less
Weight	Approx. 130 g

Thông tin bổ sung

Thương hiệu	Keyence
