Module bộ đếm Keyence KV-SC20V

Thông số	Giá trị
Model	KV-SC20V
Type	High-Speed Counter Block
Input Frequency	1 MHz
Counting Range	32 bits
Number of Channels	2 channels
Input Mode	2-phase 1 time/2 times/4 times, 2 pulses (add and subtract operation), with or without pulse direction 1, combined other output channels
Operation Mode	Up/down counting mode, time-based counting mode, preset mode, accumulate counting mode, and counting mode activation
Counting Mode	Pad, Ring
Frequency/Operation Mode	Frequency counting mode, Device A speed measurement mode, Device B speed measurement mode
Input Counting	Phase A/B/Z (preset) 6, three per channel, 5V/12V/24V DC input enabled, transmission driver, optical isolation
Input Control	Activate input channel (for input & capture), 1 point counts as 2 points, 12-24V DC input enabled, optical isolation
Output	Output merged with comparator, 2 points count as 4 points with optical isolation, rated load: under 30 VDC 0.1 A
Input Register Function	Based on external input (up to 4 points)
Input Switching Function	Constant time input switching (counts 4 types/controls 7 types)
Preset Function	Preset input/(Phase Z)/internal relay
Power Consumption	Up to 95 mA
Weight	Approx. 120 g

Thông tin bổ sung

Thương hiệu	Keyence
