Module Analog Keyence KV-AM40V (2 in/ 2 out)

SKU: KV-AM40V
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

SKU: KV-AM40V Danh mục: PLC Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	KV-AM40V
Type	A/D and D/A conversion unit
Analog Input/Output Points	Input: 2 points (differential input)Output: 2 points
Analog Input/Output Range (Voltage)	-10 to +10 V (1.25 mV 1/16000)-5 to +5 V*1(0.625 mV 1/16000)0 to 10 V (1.25 mV 1/8000)0 to 5 V (0.625 mV 1/8000)1 to 5 V (0.625 mV 1/6400)
Analog Input/Output Range (Current)	0 to 20 mA (2.5 μA 1/8000)4 to 20 mA (2.5 μA 1/6400)
Input Resistance	Voltage: 5 MΩCurrent: 250 Ω
Conversion Speed	80 μs/ch23
Conversion Precision	±0.2% of F.S. (at 25°C ±5°C)±0.4% of F.S. (at 0 to 50°C)*4
Insulation Mode	Between unit and CPU: Photocoupler insulationBetween channels: Non-isolated
Absolute Maximum Input	Voltage: ±15 VCurrent: 30 mA
Minimum Load Resistance (Voltage)	1 kΩ
Maximum Load Resistance (Current)	600 Ω
Internal Current Consumption	140 mA or less
Weight	Approx. 150 g
